Cuttlefish: A Fair, Predictable Execution Environment for Cloud-Hosted Financial Exchanges

As mentioned, there has been recent interest in cloud-hosted exchanges for reasons including better scaling, fewer outages, improved cost savings, and broader access to the financial markets [24, 19, 17, 35].

Figure 2 depicts the main components of these exchanges. At the core of these systems is the CES, which disseminates market data to all MPs through Release Buffers (RBs) or equivalents. The communication between CES and MPs typically leverages a reliable message transport [24, 19]. Then, the MPs – hosted by proxy cloud instances in the same cloud region as the CES – compute their trading decisions and forward them to the CES.³³3Cross-region deployment of VMs is feasible (e.g., through virtual network (VNet) peering [44]), but not suitable for low-latency communication [24, 19]. There, trades are first enqueued and sorted at the Ordering Buffer (OB) and then processed by the Matching Engine (ME). The ME finally updates the limit order book and generates a new batch of market data.

Unfortunately, despite their attractive properties, in our conversations with major cloud providers, financial exchanges, and trading firms, there is still a fundamental distrust of the performance properties of the underlying infrastructure. In particular, for both exeuction and communication, performance variations have the potential to invalidate the benefits of careful design, creating a world where MPs win and lose not on the strength of their algorithms but on purely external factors (e.g., temporal variation or provider monitoring/maintenance).

To illustrate, consider the simple scenario of delivering market data $x$ for ${\text{MP}}_i$ and ${\text{MP}}_j$ in Figure 3(a). Coordinating delivery to ensure $D(i,x)=D(j,x)$ is difficult due to unpredictable and unbounded path latencies. More importantly, even with simultaneous data delivery, the same hardware substrate (e.g., same server SKUs), the same software stack (OS and the MP’s trading algorithm), and the same algorithm, the exeuction time can still vary (e.g., due to different thermal state). This leads to non-deterministic submission times $S(i,y)\ne S(j,y)$, as shown in Figure 3(b). In both cases, any disparity, even at nanosecond time scales, can advantage/disadvantage an MP.

Recent measurements on cloud-hosted exchanges have quantified the danger of latency spikes in modern clouds [24, 19]. Equally important, however, is the bias and variability in execution performance, which can also occur for any number of reasons, including everything from non-deterministic software operations to machine-specific hardware wear and thermal effects, with prior measurement citing the Coefficient of Variation (CoV) of performance in bare-metal infrastructure of up to 30% [54, 38]. These are on top of noisy neighbor and hypervisor effects introduced in cloud deployments. Our benchmarks on Azure cloud, shown in Figure 1, validate the presence of these biases and variances. Even for single-tenant F72_v2 instances, with all physical cores of the machine reserved, the interquartile range (IQR) is still 20 ns with disparities exceeding $>1$ $\mathrm{\mu }$s at $p99.9$.

While in both cases it may be possible for cloud providers to try to tame this effect, for instance, by removing all management and telemetry infrastructure or carefully controlling temperature and wear, resulting in much tighter SLOs, (1) doing so would substantially cut into the cost and scalability advantages of cloud-hosted exchanges, and (2) this still does not eliminate disparities that can result in unfairness.

Existing cloud-hosted exchanges, despite focusing exclusively on communication [24, 17, 19], provide incomplete guarantees, even for R1. For example, CloudEx [17] and Octopus [18] enforce high-resolution clock synchronization among all RBs and the CES. The CES, upon generating market data at time $t$, assigns a future release timestamp $t+\mathrm{\Delta }{t}_r$ with a predefined threshold $\mathrm{\Delta }{t}_r$, allowing RBs to forward the data simultaneously. Similarly, when an inbound trade arrives at an RB at time $t$, the CES enqueues it to the OB until $t+{\mathrm{\Delta }}_d$ where the delay ${\mathrm{\Delta }}_d$ allows earlier trades to arrive within this headroom. Unfortunately, even with perfect clock synchronization – a strong assumption in distributed systems [37] – the guarantees break whenever latency spikes exceed the threshold. Such latency spikes can occur unpredictably in cloud environments [24, 19, 34]. Configuring conservative threshold values can help (at the cost of performance) but are not a complete remedy [24, 19, 13].

More recent work, DBO [24, 19], relaxes the requirement of clock synchronization and proposes logical clocks based on MP response time. Briefly, DBO offloads RBs to local SmartNICs that measure and tag each MP’s response time, while trades are being ordered accordingly at the OB/CES. This method corrects inaccuracies in simultaneous data delivery post hoc and provably guarantees Limited Horizon Response Time Fairness for of R1. However, DBO’s guarantees are limited to a specific trading pattern, namely trigger-point-based high-speed trades. Trades that do not fit this model (e.g., trades triggered using two or more data points) are not necessarily fair.

Cuttlefish takes an analogous approach by assigning virtual time to all communication and execution – down to an instruction level. Like emulation, Cuttlefish benefits from the ability to control the fine-grained progression of virtual time for each MP (pausing and skipping forward as necessary). Unlike emulation, however, low-latency algorithmic trading presents a substantially different set of goals and knobs.

Soft real-time constraints on virtual time progression. Generally, the primary concern of network emulation is fidelity to a target emulated network. The relationship between the emulator’s virtual time and wall-clock time is of secondary importance, with the most important impact being its effect on the end-to-end execution time of emulation. In contrast, Cuttlefish is a platform for trading real-world financial instruments, so consistent timeliness is critical, especially in the presence of alternative trading interfaces and external data.

Control over input frequency. Emulation’s focus on fidelity also generally assumes a “correct” emulation target. In contrast, the CES in Cuttlefish has significant control over market data delivery times – what matters is the fairness of the delivery, not fidelity to any particular execution. Cuttlefish uses this control to adjust the market data delivery rate in response to the current load and to allow lagging nodes to catch up.

Figure 5 depicts the operation of virtual time in Cuttlefish. The Cuttlefish CES operates unrestricted in wall-clock time, while the MPs track and adhere to virtual time. For simplicity, we will ignore component failures but discuss how Cuttlefish can be extended to handle them in Section 8. The notation used in the figure and the remainder of the paper are summarized in Table 1.

1. 1.

   [Figure 5(a)] For fair market data delivery (R1a), the CES picks and tags a virtual time $\tilde{D}(x)$ for the release of each data point $x$. Each MP’s local execution runtime controller ensures the release accordingly.

2. 2.

   [Figure 5(b)] For execution fairness (R2), Cuttlefish provides a deterministic accounting of compute (in virtual time). Specifically, it counts the instruction cycles executed by its platform-agnostic virtual machine substrate. This ensures that, for any ${\text{MP}}_i$ consuming an input $x$ at $\tilde{D}(x)$ and producing a trade $y$, the resulting $\tilde{S}(i,y)$ is deterministic, regardless of execution performance variations.

3. 3.

   [Figure 5(b)] For fair trade ordering (R1b), trades from an MP are marked with the virtual time at which they are generated, $\tilde{S}(i,y_1)$ and $\tilde{S}(j,y_2)$. Similar to DBO, Cuttlefish features an ordering buffer that forwards these trades to the CES based on their generation virtual time in monotonically increasing order. Thus, the ME processes $y_1$ before $y_2$ if and only if .

Strict adherence to virtual time on all MPs ensures both (R1) and (R2). Further, the CES’s ability to bridge wall-clock and virtual time ensures minimal delta between the two (Section 8).

Similar to other cloud-hosted exchanges [24, 19], VMs executing MPs are co-located in the CES region for low-latency services. Unlike existing systems, however, users of Cuttlefish build on a platform-agnostic virtual machine substrate clocked by virtual time cycles, mediating all MPs’ computational and I/O operations through this abstraction.

Figure 6 depicts Cuttlefish’s high-level architecture. For simplicity, most of our discussion will assume homogeneous, single-threaded market participants and the market data stream as the only input to the ecosystem. We describe the integration of external data in Section 7, extension to heterogeneous compute in Section 11, and multi-threading support in [57].

Building on the typical cloud-hosted exchange architecture, Cuttlefish introduces:

①MP algorithm representation via eBPF VM bytecode [Section 6]. To account for the amount of execution deterministically, Cuttlefish leverages a platform-agnostic IR that is based on the eBPF Virtual Machine (VM)⁴⁴4A virtual machinery abstraction, not to be confused with physical cloud VMs. instruction set. Cuttlefish advances virtual time based on the consumed number of VM instruction cycles, allowing it to abstract out potential variances in the underlying infrastructure. Cuttlefish also adapts eBPF user-space libraries to support a simple but expressive programming interface. Cuttlefish verifies, instruments, and translates this code from MPs to native assembly for the underlying computation platform for efficient execution.

②Virtual time execution runtime (VT-RT) [Section 7]. Cuttlefish develops a runtime execution environment that can efficiently utilize all available cores to execute the binaries for MPs allocated to the same cloud VM. It also manages a range of real-time operations for the responsible MPs, including tracking and advancing the virtual time, data delivery, and local batching of trades and heartbeat to the central CES for ordering based on the submitted virtual time.

③Virtual time control (VTC) [Section 8]. Cuttlefish integrates a virtual time control algorithm for the CES to assign virtual market data release times. By controlling virtual time assignment, the CES controls how much compute throughput is available to each MP. This is crucial to mitigating underlying network latency spikes or slowdown in execution behaviors.

Cuttlefish prioritizes fairness, which is the primary concern for exchanges [47, 24, 19]. This trade-off is intentional, as a slower exchange operating within the higher latency bounds of public clouds can still meet market needs, provided it delivers market data and accepts orders uniformly across all participants [24, 47, 39].

In exchange for fairness, Cuttlefish incurs modest overheads on MP execution. Some of this is due to the extra instrumentation to track and control virtual time ($\sim$2–20%). More fundamentally, guaranteeing that all MPs have equal opportunity means that system-wide progress is gated on the slowest node. This limitation is intrinsic to any fair system. Prior work like DBO and CloudEx noted similar limitations when equalizing network delay; Cuttlefish incurs the same for execution.

Despite these trade-offs, in our evaluation on a public cloud and 100 MPs (approximately the maximum scale of most existing exchanges [24, 27]), Cuttlefish incurs low overhead in both latency and throughput under real-world performance variation, approximating the limits of the underlying cloud hardware (Section 10.3). If higher throughput is needed, better hardware or multi-threaded execution ([57]) can help. Also, the observed latency is well within the requirements of many major exchanges.⁵⁵5A major exchange, IEX, prides itself on fairness with a 700$\mathrm{\mu }s$ latency [27, 24]. Regardless, Cuttlefish still guarantees fairness and predictability in all cases.

Moving to a cloud-hosted solution fundamentally requires MPs to trust the cloud provider and trading platform to not steal or manipulate the MP trading code and execution [17, 19, 24]. Such requirements are typically enforced through contracts, log auditing, privacy laws, and regulatory bodies such as the SEC, and the same prohibitions apply here. Recent advances in hardware (e.g., Intel SGX [10]) as well as efforts in cloud confidential computing [46, 1, 26] could also benefit Cuttlefish by providing cryptographic attestation and secure enclaves during both instrumentation and execution. An exploration of these mechanisms is out of the scope of this work.

For the provider’s side of the provider-MP relationship, following prior work [24, 19, 17], we assume that all core system components – including release and ordering buffers – are trusted and protected against tampering. As we discuss in Sections 6.2 and 8, Cuttlefish’s abstractions naturally defend against problematic instructions or program structures. Otherwise, MPs can utilize the system in arbitrary ways, including trying to slow down virtual time advancement through interaction with the CES and execution engine.

For all other interactions (e.g., MP-to-MP or to/from malicious third parties), we assume secure and exclusive communication channels between MPs and Cuttlefish components using standard public cloud features, such as security groups [24, 19] to prohibit outside communication with any of these entities. While it is possible that malicious actors may attempt to indirectly influence these connections, e.g., through datacenter-level DDoS attacks, cloud providers themselves are already quite capable of mitigating, defending against, and provisioning for these types of attacks.

Cuttlefish runtime interfaces with CES via the data dispatcher and the trade aggregator, both exchanging data streams over a reliable transport layer.

Data dispatcher. The dispatcher manages inbound market data, each coming with an assigned virtual release time.

Trade Aggregator. The trade aggregator gathers tuples from MPs, each comprising a trade decision $y$ and its virtual submission time $\tilde{S}(i,y)$. These tuples are locally sorted by submission time, batched, and sent to the OB for global sorting. The aggregator is additionally responsible for sending heartbeats to the CES to indicate the latest virtual time reached by all local MPs. The OB uses these heartbeats to decide when it can forward the trade with the lowest virtual submission time in its buffer to the CES safely (i.e., there are no in-flight trades with lower virtual time). This localized handling of sorting and heartbeat calculations enhances the CES’s scalability.

Cuttlefish’s runtime allows consolidating multiple MPs into multi-core VMs for efficiency. It also maximizes CPU utilization (for execution-throughput) and eliminates blocking operations along the data path (for latency). Central to its workflow are the worker threads that execute MPs in parallel, each affined to a dedicated CPU core and configured to run a loaded MP binary. Interaction with the dispatcher and aggregator is streamlined using lock-free, cache-efficient Single-Produce-Single-Consumer (SPSC) rings to minimize processing latency.

The worker threads operate in a busy loop with minimal stalls (e.g., context switching) during the execution. It first polls a batch of command items that contain market data from the command ring. For each market data $x$ processed by ${\text{MP}}_i$, the worker thread updates the virtual time and invokes the binary with the new market data immediately. Each worker then runs hardware binaries instrumented for uninterrupted virtual time advancement, as outlined in Section 6.2. During execution, MP handlers access the KV store in a thread-safe manner and invoke the redirected function that enqueues trades to the ring with a virtual submission time of the submit_trade calls.

In addition to supporting internal data feeds from the CES, Cuttlefish also accommodates external data sources. These interactions are done through a designated gateway (GW) node, as shown in Figure 6, which enforces an additional virtual time latency comparable to that of the public Internet.⁶⁶6A modern commodity switch can provide Tbps capacity [49, 50], which is sufficient to handle typical quantities of external data to exchanges. The GW can scale beyond a single node with a shared clock. Just as with current exchanges, we expect that MPs can and will leverage a variety of optimization for these messages, e.g., microwave [7, 6] and satellite [25, 51, 28] networks to surpass wireline $c$ limitations, and/or employ human oversight to tweak parameters in response to changing conditions or unexpected events. Cuttlefish’s goal is only to ensure that the post-GW transmission and delivery of the data is fair and predictable. MPs can access the data through the subscribed data context input to the handler, just as they do with normal CES data. We detail the mechanism in [57].

Cuttlefish’s virtual time control targets two goals:

1. 1.

   Minimizing latency ($L(vt)={\widetilde{\text{OB}}}^{-1}(vt)-{\widetilde{\text{CES}}}^{-1}(vt)$), defined as the time difference between the CES releasing market data with virtual time $vt$ (${\widetilde{\text{CES}}}^{-1}(vt)$ ) and when the OB hears from all MPs until $vt$ (${\widetilde{\text{OB}}}^{-1}(vt)$). In simple terms, latency here refers to the minimum time between when market data is produced at the CES and when a trade from an MP using this data can be executed. This definition extends previous end-to-end latency concepts [24] for trades ordered per virtual time.

2. 2.

   Maximizing overlay execution-throughput $\theta =\mathrm{\Delta }vt/\mathrm{\Delta }t$. This represents the rate of virtual time advancement at the CES or, equivalently, the number of IR instruction cycles available to each MP (per unit of wall-clock time) to process the incoming market data.

Note that neither of these goals affects correctness, fairness, or predictability. Rather, a good virtual time assignment is important for purely performance reasons. Specifically, virtual time assignment that is too slow can limit the execution-throughput of the exchange, even when the underlying MPs are capable of supporting a higher virtual-time throughput. Conversely, virtual time assignment that is too fast can increase worst-case $L(vt)$ due to MPs that are lagging behind.

As Cuttlefish seeks to guarantee fairness across all MPs, stragglers (depicted in Figure 11) can influence virtual time control. Stragglers can arise for two reasons. First, increased network latencies delay market data delivery to MPs, slowing virtual time progression. For example, in Figure 11(a), a spike in latency from CES to an MP results in latency growth from $L(v{t}_1)$ to $L(v{t}_2)$. In reality, network latencies for both paths (CES-to-MP or MP-to-OB) can affect $L(vt)$. Virtual time assignment should try to mitigate the effect of such spikes. Second, execution slowdowns at an MP (e.g., due to change in processor frequency) can reduce the rate of virtual time progression, cumulatively affecting latencies if these slowdowns are prolonged. Figure 11(b) illustrates a simplified example of this effect.

To account for them, Cuttlefish presents an easy-to-reason-about approach by coupling its virtual time assignment with real-time evolution. We detail the assignment algorithm in [57]. The key idea of our algorithm is similar to that of BBR congestion control protocol [8]. In particular, Cuttlefish measures ${\tau }_i$, which is the estimated computational capability of ${\text{MP}}_i$ (i.e., how many virtual cycles can the executing engine of ${\text{MP}}_i$ process per unit wall-clock time). We then control the virtual time progression rate based on the bottleneck compute capacity, $\min ({\tau }_i)$. Similar to BBR, Cuttlefish applys a window cap on the max “in-flight” virtual time as a guardrail to prevent excessive virtual time assignment in worst-case scenarios.

As described, any MP failure will halt the progress of virtual time. Cuttlefish incorporates timeouts at the CES to detect such events.⁷⁷7Spurious timeouts may degrade performance, but will not affect fairness. Because of the determinism of virtual time, with periodic check-pointing of the MP state, the CES can restart and/or relocate such failed components.

We further note that eBPF uses predefined key-value stores for managing state, which makes identifying state and replicating it straightforward. Cuttlefish is also amenable to replication of the MPs themselves. This approach can potentially mask the impact of failures on virtual time progression (§10.4).

An alternate choice would be to remove the failed MP from the VTC assignment and trade-forwarding logic, and then do a clean restart. The failed MP incurs unfairness in this case. In some abstract sense, Cuttlefish is subject to a CAP-theorem-like limitation: here, the choice is between fairness and progression of virtual time progress in case of failures.

CES failure. CES fault tolerance is beyond the scope of this work; to the best of our knowledge, existing CESes also rely on state replication (e.g., of the order book) for fault tolerance.

While MP code will run alongside other MPs and Cuttlefish components, Cuttlefish benefits greatly from its IR abstraction, basis in virtual time, and validation process (Section 6.2). Potentially problematic instructions or program structures (e.g., attempts to access system memory or cycle counters for creating side channels) are explicitly disallowed. Communication is similarly restricted. As mentioned in Section 5, Cuttlefish adopts a model that forbids MP-to-MP communication similar to prior proposals [24, 19]. However, whereas prior work punts on enforcement, Cuttlefish’s constrained runtime provides natural avenues to guarantee it.

Within the confines of the system, the main potential avenue of attack for MPs is the manipulation of virtual time. Note that MPs with fewer instructions per invocation do not affect system-wide progress, as virtual time advances independently. Instead, MPs might try to deliberately slow their virtual time advancement speed for a chance to influence $\min ({\tau }_i)$ (if they are the slowest MP in the system) by picking sequences of instructions that have the largest ratio of real-time cost to virtual-time cost. Conversely, if they are already the slowest MP, they could speed up to try to accelerate virtual time advancement. Within Cuttlefish, there is no advantage to manipulating the advancement speed; instead, differences only arise in interactions with external communication and events. We note that the impact is limited: Cuttlefish’s GW ensures that external coordination is inefficient (Section 7) and the extent of manipulation is constrained to the gap between the “slowest” virtual program and the second slowest MP. In the end, however, the critical guarantee that Cuttlefish provides is that any variability in virtual time advancement speed is experienced equally by all MPs.

Cuttlefish supports the end-to-end workflow for MP handlers described in Section 6, exposing a single-header interface for Cuttlefish’s virtual time services. For verified eBPF bytecodes provided by users, Cuttlefish embeds virtual time tracking transparently through binary writing, while achieving high performance by leveraging the existing eBPF JIT compiler to emit native code [30].

By default, Cuttlefish assigns the virtual time for eBPF instructions based on the equivalent hardware instructions on standard CPU models (e.g., x86_64) and leveraging previous studies that have extensively quantified their costs per machine cycles or reciprocal throughput in modern hardware architecture [14]. For example, BPF_ADD is assigned one virtual time unit, with other operations, including handler invocation and BPF_CALL instructions for built-in service APIs such as the access to the KV store, scaled accordingly. In Cuttlefish, the relatively small eBPF instruction set [29] simplifies the process. While actual instruction cycle times (e.g., memory accesses) can vary in wall-clock time due to microarchitectural effects such as caching, these variances are abstracted away in the virtual time domain. The idea behind such an assignment is to, as much as possible, reduce the dependency of $\tau$ on the IR instructions used by the MP in its code. However, exchanges can customize their cost model according to their needs – as long as the models are transparent, the system is fair and predictable.

Cuttlefish employs a reliable, message-based transport [42] for its dispatcher and trade aggregator thread, interfacing with the CES/OB. Worker threads are affined to dedicated cores and are responsible for invoking MP handlers. To facilitate communication between workers and the data dispatcher, Cuttlefish uses a cache-efficient, lock-free Single Producer/Single Consumer circular buffer implementation to instantiate the market and trade rings respectively as detailed in Section 7.

While Cuttlefish currently focuses on a CPU-based interface and runs on common x64-based cloud VMs, the choice of eBPF IR allows operators to benefit from a broader ecosystem, including mature toolchains that compile eBPF bytecode to ARM64 [30] or offload it to accelerators such as FPGAs [5, 15].

In the extreme case, virtual time is flexible enough to support differentiated instance types and price points. For example, clouds could charge more money for more memory or faster processing (via scaled-up virtual time throughput); they could also sell instances with, for example, 8 CPU cores and 4 FPGAs (by leveraging alternative eBPF backends and the techniques in [57]). While this type of support is well out of scope for this paper, one could imagine an IaaS abstraction as rich as traditional cloud offerings, but where each compute device is metered using virtual time.

Securities represent and interact with global assets, and Cuttlefish is only designed to mediate the low-latency algorithmic trading API of the specific exchanges that adopt it; financial activity can occur outside the exchange and even through the slower alternative APIs of an adopting exchange.

In all cases, Cuttlefish eliminates variability and bias between MPs in the exchange. While it potentially also slows them compared to the rest of the world, for securities listed solely at the adopting exchange, Cuttlefish will still be the fastest way to issue buy/sell orders (Section 7). Securities cross-listed at multiple exchanges (Cuttlefish or otherwise) may present opportunities for arbitrage, but that is no different than today, and crucially, the Cuttlefish-enabled cloud platform will never be the determiner of which MP wins the race. As others have noted [47, 24, 7, 19, 39], this prioritization – fairness over pure latency – is a desirable one.

Our prototype currently runs with 100 MPs, with the CES broadcasting market data at approximately $100\mathrm{\mu }$s intervals. In this setup, the primary bottleneck lies in the CES, which must serialize inbound data ingestion and outbound market data dissemination. One can mitigate bottlenecks with faster processors and high-bandwidth NICs for the CES, which translate to scalability directly. “Beefier” VM SKUs on the MP side can also help, as Cuttlefish’s execution runtime is also designed to scale up with the number of cores, which allows greater MP co-location per machine. To that end, modern cloud providers can offer “beefy” VM SKUs with over 100 vCPUs [45].

As the number of MPs increases further, components like OB can be scaled out using a distributed architecture: multiple OB instances can be deployed, each responsible for a disjoint subset of RBs (e.g., sharded by trading symbol). These distributed OBs can safely dequeue and batch pending trades, forwarding them to a final merge layer colocated with the matching engine (ME) for order finalization [24].

In parallel, Cuttlefish can benefit from ongoing advances in cloud networking infrastructure. Techniques such as traffic admission control and prioritization [21, 59] can reduce or bound end-to-end latencies. Additionally, scalable multicast engines [26, 47, 18] can help scale CES’s market data dissemination, enabling high-rate, low-latency delivery to a larger number of participants.
