Deep Learning and Knowledge Integration for Music Audio Analysis

In the last few years, the fields of computer vision and natural language processing have witnessed a new generation of general-purpose models that can be used for a wide variety of downstream applications [1]. These are pre-trained models using a domain-specific pretext task before applying them to the downstream task of interest. The pretext task is usually conceptually simple and does not require side information such as expensive and often strongly biased labels, but powerful in the sense that a comprehensive understanding of the input is needed to perform well. These approaches also enormously benefit from scaling up model expressivity (such as Transformer models) and dataset size, which are enabled by hardware improvements such as Tensor Processing Units (TPUs).

If such an approach was applied to the music domain, we could obtain models that perform many different music audio analysis tasks even when only a few annotations for a task are available. However, music audio is different from language and vision, and we have not yet found a suitable music processing task with the same simplicity and strength as existent in other domains. Therefore, we review some pretext tasks used in existing approaches and discuss which tasks might be suitable for the music domain.

In natural language processing, randomly masking input tokens and asking the model to reconstruct them was used successfully as a pretext task [2]. Here, one needs to understand the context and semantic meaning of a sentence and its words to predict masked tokens. Similarly, in computer vision, we can predict randomly masked image patches [3]. However, it is questionable whether applying this directly to music audio spectrograms would result in an equally powerful pretext task due to the differing nature of spectrograms and images.

Other generative learning methods are promising pretext tasks, as they encourage a model to learn many semantically relevant features in the process. Generative models can be constructed in different ways, one of which is by using an autoregressive approach. Assuming that the input data can be represented as a sequence of elements, the model must predict the next element in the sequence, given the previous ones. In the NLP domain, [4] used a Transformer-based sequence model to predict the next word given the previous ones, which turned out to acquire many features useful for various downstream tasks. Similarly, making a model continue a given music piece could also yield semantically meaningful features – the usefulness of the Jukebox [5] features can be seen as an early example of such an approach. However, it is more difficult to identify where the relevant features from the model need to be extracted since auto-regressive models do not yield an explicit latent representation. This fact is in contrast to reconstruction-based generative models, such as variational auto-encoders (VAEs) and, in particular, VAEs using vector quantization (VQ-VAEs) that were shown to be effective at compressing music signals into short sequences of tokens [6]. Finally, the flow-based approach has shown some promise in computer vision, where the data is mapped to an equally high-dimensional but ordered latent space using a bijective function. Since the input is not compressed in this approach when moving to the latent space, it might be better suited for tasks where input details are relevant but worse for more abstract tasks.

An alternative task, called contrastive self-supervised learning, is to learn to compare different views of the same input such that the representation puts similar inputs closer together [7]. While it can learn a representation invariant to musical properties through data augmentation, it can be counterproductive for tasks dependent on these properties.

Our discussion is grounded on the specificities of music, on the desirable properties we would like a self-supervision task to highlight, and on the most promising musical applications that could come out of this.

As outlined in the Dagstuhl Seminar’s description, data-driven approaches tend to employ confounding factors to achieve results. Based on this observation, I raised a variety of questions in my talk.

• $\mathrm{■}$

  When is the use of confounders actually a problem, and when is it just fine?

  • –

    In other words: Let us say a causal relationship between input and output exists, but the underlying information is hard to extract (which is usually the case). At the same time, some other information is easy to extract but only correlates with the output. Depending on the problem, we mix the uncertainty we get from the difficulty of extracting the proper information with the certainty that we can derive proper conclusions once we have that information. On the other hand, we could use correlations (where we often cannot measure how correlated or causal a factor is) and do everything to optimize average performance. If the latter is a problem, why is 95% of the ML community doing just that and humanity finds it useful?

  • –

    One could argue that we might want to exclude confounding factors if we want to build a causal model of (some aspect of) music, where application performance does not matter, but performance is only helpful to compare different causal models to say which explains the data better. One provocative question is whether we, as MIR researchers, are interested in causal models. Do we understand the underlying principles of music theory and sound production practice? In other words, which aspect of music can not be broken down yet into causal components? Is there something about music we have not yet understood?

• $\mathrm{■}$

  In some cases, the use of confounders is why models do not generalize to new data domains (recording conditions, types of music, and so on). From that perspective, let us discuss when the integration of musical knowledge is actually the best solution to increase generalization capabilities and what “best” means in this case.

• $\mathrm{■}$

  To answer the former question, we should look into alternatives to improve generalizability.

  • –

    In this context, we should discuss what adversarial attacks could solve. What if we encourage submissions that take existing methods and code and try to break it in interesting ways. What is the average Euclidean distance when modifying the input until we observe a confusion or perfect result (for classification problems)? What happens with out-of-domain data and unobserved data? Alternatively, could we encourage authors to attack their own systems? For example, the availability of adversarial attacks on speaker ID systems has led to tons of work to make such systems more robust. What can we learn from that?

  • –

    Is there enough work to understand the error surfaces of neural networks? We have regularizers of all sorts, aiming to make the error more Lipschitz in one way or another. What does that mean? One aspect often discussed in this context is flat areas in error, where small parameter changes only lead to small changes in the output. As music is so structured, is there something here to help us characterize and identify such areas and potentially inspire us to create corresponding regularization approaches?

  • –

    Differentiable signal processing components have recently spawned some interest in the community. Do we understand how those should be seen and used in the context of confounders? There are also new stochastic tangent methods to estimate a gradient for non-differentiable components. Is this an option?

  • –

    Before the neural network hype, Bayes nets and probabilistic modeling were all the rage. Some of these could be seen as causal models. If the goal is to build and verify proper/causal models for aspects of music, should we not simply ditch neural networks and application performance and go back to these approaches? Alternatively, stochastic nets, such as Bayes neural networks, have recently attracted more and more attention in the theoretical ML world. Is this getting good enough that we should investigate if and how such approaches could build a bridge between the two worlds?

Machine learning (ML) now touches all of our lives. Such systems recommend which videos to watch, where to go on holiday, and how to get there. Though progress has been astounding, these ML models fall short when it comes to non-standard examples and subjective applications, such as analyzing underrepresented music genres, understanding people with accents or speech impediments, or recognizing faces from underrepresented ethnicities. ML-based models fall short because they are designed and trained to work well on “averages”. In this context, I discussed in my talk how we could take steps to develop the next generation of ML models to close the gap between the models’ output and the users’ need. I argued how we could leverage several recent advancements in self-supervision, representation learning, and multimodal data analysis to move towards more user-centered ML.

In expressive performance modeling or performance style analysis (e.g., for piano music), it is common to use hand-crafted performance features instead of directly using audio or MIDI representations. One of the reasons is that it makes the problem more focused on how someone played, and not what or in which acoustic condition someone played. Researchers who are using performance features believe that these hand-crafted features somehow better capture the musical intention of the performer. Even when the output of a performance is encoded as audio or MIDI, we assume that hidden underlying features (e.g., related to musical tempo) are present. Explaining a musical performance as a function of an underlying musical tempo assumes that each note’s position in time depends on the performer’s internal musical tempo. Using this strong assumption, computational systems for expressive performance modeling have succeeded in mimicking human performances [1, 2].

Most recent deep learning (DL) approaches aim to model outputs in an end-to-end fashion. However, there are examples where those approaches fail, such as generating structured musical pieces with WaveNet trained on piano recordings [3]. On the other hand, the success of DDSP [4] with a limited amount of training data is an example of the effectiveness of modeling underlying features of instrumental sound (which is a combination of harmonic oscillations) instead of modeling the final observable output (i.e., waveform samples).

Still, counterexamples show that only modeling observations without explicit assumptions may be enough to model the complex structure of musical sounds and music. OpenAI’s Jukebox [5] models music audio without explicitly modeling underlying features, such as notes, chords, or instrumentation. Also, recent research shows that neural networks that were trained to model observations also learned characteristics of underlying features. Examples are the usage of audio representations obtained by Jukebox for retrieval tasks [6], or the usage of 2D GANs to infer 3D depth [7].

There are further examples in DL-based MIR research, such as using explicit modeling of drum sounds for transcription [8], or using MIDI transcriptions instead of audio for composer identification [9]. However, it is still an open question whether it is beneficial to explicitly model underlying features or model end-level observations with larger-scale training data.

The problem of aligning two time series is central to many areas of music information processing (MIR), including music synchronization, lyrics alignment, and music transcription. At the same time, more and more MIR tasks are approached using deep-learning (DL) models that consist of differentiable building blocks. In traditional music processing, the primary technique used by MIR researchers for aligning sequences of music data is dynamic time warping (DTW) [1], which finds a minimum cost alignment between two sequences, given appropriate feature representations and a suitable cost measure. However, the standard DTW recursion involves the computation of hard minima and, therefore, is not differentiable everywhere. Recently, this technique has been modified to be fully differentiable by using a “soft” way to compute minima in an approximative fashion [2, 3]. This strategy opens up the possibility of utilizing a soft DTW variant inside DL systems and backpropagate gradients through an alignment.

In this talk, we focused on music synchronization as a motivating scenario to demonstrate how soft alignment techniques might be helpful in MIR. The idea is to replace a classical pipeline based on chroma features and DTW with a DL-based approach using learned features and a soft DTW variant. We discussed several challenges arising from this related to trivial solutions and the efficiency of the gradient computation. The subsequent discussion focused on other application scenarios, in particular lyrics alignment and lyrics-informed source separation [4]. Furthermore, we discussed the relationship between the soft DTW variant and other techniques such as the connectionist temporal classification (CTC) function, the Viterbi algorithm, and the Baum–Welch algorithm. We found that the soft DTW variant allows for a cleaner formulation of the lyrics alignment problem than commonly used approaches such as CTC, but several technical challenges remain to be solved.

During the Dagstuhl Seminar, we discussed some of our recent work on automatically detecting musical patterns in audio recordings with a particular focus on leitmotifs. These motifs are specific patterns associated with certain characters, places, items, or feelings occurring in an opera or a movie soundtrack [2]. Detecting such leitmotifs is particularly challenging since their appearance can change substantially throughout a musical work. Based on a dataset of 200 hours of audio with over 50 000 annotated leitmotif instances, we explored in [1] the benefits and limitations of deep-learning techniques for detecting leitmotifs. To investigate the robustness of the trained systems, we tested their sensitivity to different modifications of the input. We found that our deep-learning systems seem to work well in general. However, a closer investigation reveals that they capture confounding factors such as pitch distributions in leitmotif regions rather than identifying characteristic musical properties such as rhythm and melody. Thus, our in-depth analysis demonstrates some challenges that may arise from applying deep-learning approaches for detecting complex musical patterns in audio recordings. In personal conversations with Dagstuhl participants, we discussed how deep learning systems need to be adapted to detect musical patterns robustly. In particular, we found that these systems need to explicitly model the underlying musical structures (such as melody and rhythm) to prevent them from exploiting confounding factors.

With Dagstuhl being a good place for joint reflection, I took the audience along in a central question I have increasingly been pondering: What does it mean to “work as intended”? Considering the nature of our academic research and the applied nature of our work, do we succeed in the way we substantiate and communicate in our papers that our contributions are relevant and impactful? Are our contributions indeed relevant and impactful? What would a contribution need for this? In our discussions throughout the Dagstuhl Seminar, these considerations turned up several times when colleagues raised questions on current methodologies and metrics (associated with the question on “what would (not) get someone a paper”).

Looking at topics surrounding deep learning and its applications, I also engaged in discussions on how to teach these topics to our future generations. I have been wondering whether we currently show and teach the proper examples to them and whether we encourage them to “work as intended” in responsible ways in the future. To illustrate this, in a joint talk with Bob Sturm, I illustrated how misconceptions and bad modeling choices (that a naive student may easily make) led to the childcare benefits scandal in The Netherlands. Next to this, I engaged in discussion groups on MIR teaching, where the broad consensus was that music uniquely gives opportunities to really engage with and consciously perceive data. As part of the discussion following my joint presentation with Bob, I finally raised a controversial question: Is the work we present as “science” actually scientific? Methodologically, I think we are mixing aspects of design, science, and engineering while still seemingly upholding “science” as the most important of these three. However, is this really justified? As a group, we did not reach a consensus on this matter, but lively discussions were held that will hopefully extend beyond this seminar.

Integrating musical knowledge into neural networks can be viewed from two perspectives:

• $\mathrm{■}$

  Using our prior knowledge about a task to guide computation (“telling the model what to obtain”).

• $\mathrm{■}$

  Identifying our underlying perceptual mechanisms to construct blocks or learning paradigms to guide the model toward knowledge extraction without enforcing a specific output (i.e., “telling the model how to obtain it”).

Both views raise challenging questions. In my presentation, I mainly discussed the latter view, even if it is unclear what our knowledge extraction mechanisms are or how they can be transferred to machine learning models. This hodgepodge includes exploring how we codify patterns and repetitions, develop a sense of hierarchical connections and structures, identify timbral spaces and textures, create context-dependent analysis, or enjoy music through a balance between predictability and surprise.

I find the human capacity to distill complex and compact representations to form high-level ideas at several hierarchical levels and our capacity to work with them fascinating. For instance, we can not only associate a new song to an existing artist (a pure classification task) but also recall it in a few instants without any external musical trigger. This capability shows that we have a deep understanding of what that artist is. The ability to develop hierarchical connections from low-level local elements (i.e., how we process information as a part of a whole) is essential to our knowledge distillation. How to mimic this ability when developing “intelligent” models [1, 2] is a fundamental research question. One main challenge is how to induce this part–whole behavior in our systems to let them derive complex but compact high-level musical ideas from local acoustic observations? These ideas open many other stimulating research questions:

• $\mathrm{■}$

  What are the learning paradigms as well as model and task definitions that induce the right invariances needed to create these capsules of knowledge?

• $\mathrm{■}$

  What is the ideal final high-level representation: a single one, a parse tree, or a graph?

• $\mathrm{■}$

  How do we overcome the problem of dynamically allocating model resources (e.g., to account for the number of essential elements and hierarchical levels that will undoubtedly vary from one song to another)?

• $\mathrm{■}$

  Can we distill knowledge by “listening to” the audio several times and take advantage of overfitting?

By finding answers to these questions (and raising many more), we may be able to capture compact but rich representations and better understand knowledge extraction and model behavior.

Nonnegative Matrix Factorization (NMF) is a powerful technique for factorizing, decomposing, and explaining data [4]. Thanks to its nonnegativity constraints and the multiplicative update rules that preserve these constraints in the training stage, it is easy to incorporate additional domain knowledge that guides the factorization to yield interpretable results. On the other hand, deep neural networks (DNNs), which can learn complex non-linear patterns in a hierarchical manner, have become omnipresent thanks to the availability of suitable hardware and software tools. However, deep learning (DL) models are often hard to interpret and control due to the massive number of trainable parameters. In this talked, we reviewed and discussed current research directions that combine the advantages of NMF-based and DL-based learning approaches. To make our discussion more concrete, we considered an audio decomposition application with the objective to decompose a music recording’s magnitude spectrogram into musically meaningful spectral and activation patterns [1]. In this context, we addressed the following questions:

• $\mathrm{■}$

  How can one redraft an NMF-based decomposition as a DNN-based learning problem using autoencoder-like network architectures? Such an approach was originally proposed in [7].

• $\mathrm{■}$

  How can one retain nonnegativity constraints during the optimization process? Such approaches may be based on projected gradient descent methods [5] and other optimization schemes [10].

• $\mathrm{■}$

  How can one incorporate additional (score-based) prior knowledge into DNN-based models? In this context, one may apply ideas from structured regularization [9] and structured dropout [2].

• $\mathrm{■}$

  How can one simulate stacked NMF-like decomposition technique [8] within the DL framework, thus extending traditional flat NMF architectures?

• $\mathrm{■}$

  What is the effect of invertibility constraints of specific layers on the interpretability of the resulting models? How can such conditions be enforced at the training stage? A first approach was described in [3].

By systematically combining and transferring ideas between NMF-based and DL-based learning approaches, our goal was to understand better the interaction between various regularization techniques and DL-based learning procedures while improving the interpretability of DL-based decomposition results. Furthermore, using audio decomposition as a concrete example, we showed how education in machine learning might be supported by considering motivating and tangible music processing applications [6].

The gist of deep learning (DL) is to learn representations from data to better predict the output or better structure the data within an embedding space. These representations can be learned through neural networks as part of an entire processing pipeline for a given task. For many music information retrieval (MIR) tasks, state-of-the-art neural network models still use time–frequency audio representations designed by explicitly exploiting domain knowledge. Examples are perceptually motivated Mel spectrogram or log-frequency spectrograms obtained by applying a musically motivated constant-Q transform. A recent research trend aims to obtain data-driven audio representations directly from raw audio waveforms (e.g., in sparse coding and convolutional neural networks). While these approaches have shown promising results in, e.g., music classification tasks, they require large-scale datasets to be successful (e.g., one million songs). Furthermore, these methods do not significantly outperform Mel spectrograms, and the learned (convolution) filters are often hard to interpret. As a compromise between hand-designed and fully-learned audio representations, researchers have attempted to learn filters with constraints (e.g., phase invariance) or learn only parameters of pre-designed filter prototypes. While reviewing recent work on this topic, we discussed possible research directions for learning audio representations and their potential for music processing.

Music source separation (MSS) aims at decomposing a music recording into constituent sources, such as a lead instrument and the accompaniment. Despite the difficulties in MSS due to the high correlation of musical sources in time and frequency, deep neural networks (DNNs) have led to substantial improvements to accomplish this task [1, 2]. For training supervised machine learning models such as DNNs, isolated sources are required. In the case of popular music, one can exploit open-source datasets which involve multitrack recordings of vocals, bass, and drums. For western classical music, however, isolated sources are generally not available. In this talk, we considered the case of piano concertos, which are composed for a pianist typically accompanied by an orchestra. The lack of multitrack recordings makes training supervised machine learning models for the separation of piano and orchestra challenging. To overcome this problem, we suggest generating artificial training material by randomly mixing sections of the solo piano repertoire (e.g., piano sonatas) and orchestral pieces without piano (e.g., symphonies) to train state-of-the-art DNN models for MSS. Furthermore, we propose a test-time adaptation (TTA) procedure, which exploits random mixtures of the piano-only and orchestra-only parts in the test data to finetune the separation quality. To this end, one may first train on an artificially generated dataset. Then, the idea is to exploit that piano concertos comprise long piano-only (e.g., in the Cadenza) and orchestra-only (e.g., in the Exposition) sections. Using these sections, one can generate synthetic mixtures for the test item at the testing stage to adapt the model and enhance the separation. In this context, we discussed the following points:

• $\mathrm{■}$

  Although random mixes are not musically plausible, they already yield an acceptable separation quality. Would it be feasible to generate further data for this task using an orchestra part (e.g., provided by Music Minus One) of piano concertos and mix them with the piano part played by various pianists on various instruments?

• $\mathrm{■}$

  How can one design an additional loss term to better capture the onsets of the piano?

• $\mathrm{■}$

  Can generative models, e.g., GANs, help to reduce the interference between the separated piano and orchestral sources?

• $\mathrm{■}$

  Would it be a good idea to introduce hierarchical instrument classes to the network such as strings, percussion, woodwinds, and so on?

• $\mathrm{■}$

  Would it be sensible to integrate a piano transcription model into the network?

Deep learning front-ends (or encoders) refer to the first projections of a deep neural network (DNN) applied directly to the raw audio waveform. Therefore, the front-end is the DNN part that should be the most adapted to the specificities of the audio signal. Usually, the front-end transform consists of a set of 1D-convolutions applied to the waveform, corresponding to a set of temporal basis functions, kernels, or filters. Such basis functions can simply be the cosine and sine kernels of a short-time Fourier transform (STFT) or constant-Q transform (CQT), the modulus of which brings the nice phase-shift-invariance (PSI) property.

Such kernels can also be trained. For example, the authors of [1] propose to train an end-to-end DNN with a 1D-convolution front-end. In particular, the STFT is mimicked by using real-valued kernels with sizes and strides equal to the STFT window length and hop size. However, this strategy fails to reproduce the STFT’s PSI property, requiring the learned kernels to account for every possible phase shift. To reduce the number of required phase shifts to be learned, [2] proposes to reduce the length of the kernels to three samples and adopt an approach similar to the VGG-net architecture (i.e., a pyramid of projections with small kernels).

To better understand what the kernels have learned, the modulus of their DFTs is often analyzed (with the hope that those will highlight band-pass filters). To make this explicit, in the SincNet as used in [3], the kernels are parameterized as band-pass filters (represented as the difference between two low-pass Sinc kernels) with learnable parameters. While interesting, SincNet kernels still do not provide PSI. To ensure PSI, [5] extended the SincNet to the Complex-Gabor, which, apart from bringing the PSI, also provides the best time–frequency trade-off. For the same purpose (getting PSI projections), [6] proposed to define the imaginary kernels as the Hilbert transform of the learned real-valued kernels. Recently, Ditter and Gerkmann [4] showed that it is possible to reach good results using an untrained multi-phase gammatone filter bank. As opposed to Fourier-like kernels, the projection is performed with amplitude-modulated kernels.

To gain the benefits of all the previous approaches, we recently proposed extended Hilbert–Bedrosian kernels, where we learn both a modulating and a modulated career basis kernel [7]. The proposed transform achieves the PSI property as well as an envelope-shift-invariance property. We show that we can use large temporal kernels (as the Fourier transform does), hence reducing the overall computational cost with state-of-the-art results for ConvTasNet-like architectures.

Like many other multimedia-related research areas, music audio analysis has rapidly moved towards pure data-driven deep learning models where domain knowledge is deduced from the processed data. Current state-of-the-art supervised deep learning methods for music source separation require an aligned dataset of mixtures with corresponding isolated source signals. Such datasets are difficult and costly to acquire. In a recent and preliminary study [1], we proposed a novel unsupervised model-based deep learning approach to the specific use case of choir singing separation. In this work, we represent each source by a differentiable parametric source-filter singing voice model. Then, we train the neural network to reconstruct the observed mixture as a sum of the sources by estimating the source models’ parameters given their fundamental frequencies. We believe that integrating domain knowledge in the form of audio models into a data-driven method is key to developing efficient and more frugal machine listening systems. After a brief presentation of this work in the Dagstuhl Seminar, we discussed the different research avenues for exploring and extending this concept of model-based deep learning for music audio analysis.

Understanding generalization in deep learning has been one of the major challenges in statistical learning theory over the last decade. While recent work has illustrated that the dataset and the training algorithm must be taken into account to obtain meaningful generalization bounds, it is still theoretically not clear which properties of the data and the algorithm determine the generalization performance. In this talk, we approached this problem from a dynamical systems theory perspective where stochastic optimization algorithms are represented as random iterated function systems (IFS). Well studied in the dynamical systems literature, such IFSs can be shown (under mild assumptions) to be ergodic with an invariant measure that is often supported on sets with a fractal structure. As our main contribution in [1], we prove that the generalization error of a stochastic optimization algorithm can be bounded based on the complexity of the fractal structure that underlies its invariant measure. Leveraging results from dynamical systems theory, we show that the generalization error can be explicitly linked to the choice of the algorithm (e.g., stochastic gradient descent), algorithm hyperparameters (e.g., step size, batch size), and the geometry of the problem (e.g., Hessian of the loss).

In my stimulus talk, I reflected on three deep questions:

• $\mathrm{■}$

  How does my work benefit the world?

• $\mathrm{■}$

  How does my work harm the world?

• $\mathrm{■}$

  How do I know?

These are questions of ethics, and reflecting on them provides reusable insights. I illustrated these with my own personal journey of research in applying artificial intelligence to Irish traditional music. Frictions caused by this research motivated me to think about whether such an application harms the world or even whether it provides a benefit – outside of my own professional success. So, I set about learning the tradition by reading, listening, and playing an instrument with a teacher. I have started participating in the tradition to understand the origin of these frictions. These reflections and personal practice have widened my perspectives and developed a new appreciation. I have enlarged my networks outside the ivory tower and am asking more enriching questions. I have deepened my interaction with the world and have become sensitive to responsible engineering – which is constantly under review.

In this stimulus talk, we focused on fostering knowledge exchange between computer vision (CV) and music information retrieval (MIR) research communities. First, there was a discussion on whether this could be beneficial by illustrating some example works on CV applications on sequential data, highlighting similar problems, and making analogies with MIR. Next, several interdisciplinary research directions were shown to provide examples for how to enable more interaction between the two communities.

Neural network architectures increasingly become general-purpose across data modalities, such as image, video, audio, and text. A recent successful example is the family of attention-based Transformer models [9], typically taking sequential data as input. In our works, we adapted this model for problems such as subtitle text alignment in sign language videos [3], text-to-video retrieval [4], and 3D human motion synthesis from textual descriptions [2, 1]. While these tasks are different, common tools can be applied since the data types for video, text, and 3D motion are all similar in their sequential nature. In computer vision, many open questions remain on how to perform temporal modeling best, on how to deal with long-term sequences, and which architecture to employ (e.g., RNNs, CNNs, Transformers, MLPs). Considering that music and audio data are also temporal, any solutions found in one field can inspire the other. Moreover, there exist shared tasks such as alignment, where, for example, subtitle alignment can borrow ideas from MIR problems such as music-lyrics alignment and vice versa.

This Dagstuhl Seminar specifically focused on knowledge integration in deep neural networks. This talk provided several examples of how our works in CV inject domain knowledge, such as physics constraints in 3D hand-object reconstruction from images [6] and differentiable human body model SMPL [10] as a network layer [2]. This discussion led to making analogies between the differentiable 3D models and Differentiable Digital Signal Processing (DDSP) tools used in MIR. Furthermore, instead of integrating, one can extract knowledge from end-to-end black-box approaches. Using the attention mechanism as a way to perform localization in long sequences implicitly is an example for such knowledge extraction [5].

Several research problems were identified to have the potential to encourage collaborations across CV and MIR communities, among which are music-conditioned dance generation [7] and visual piano transcription [8]. We expect that bringing together researchers from the two fields for these collaborative projects can facilitate general knowledge exchange as a side product.

Machine listening aims at endowing a machine with the ability to perceive and understand audio signals as humans do. It can be applied to different audio domains such as music, speech, and environmental sounds. Nowadays, approaches based on deep learning have become mainstream tools and achieved state-of-the-art performance in multiple research areas, including machine listening. A deep learning model that generalizes well needs to be trained on a large amount of labeled data. While it is easy to collect a large amount of audio data, labeling them is very costly and often requires expert knowledge. Therefore, current studies in machine listening often suffer from small datasets, which lead to poor generalizability and small vocabulary. Existing strategies tackling this labeled data scarcity issue often still require a significant amount of human effort [1] or have generalizability issues when applied to real audio [2]. To address this, we propose a new perspective that instead of focusing on collecting more labeled data to train a giant universal model, we aim for a flexible and customizable system that can adapt to different tasks quickly with the help of minimal supervision from human input. We envision a paradigm where the model can learn to recognize a new target sound at inference time in a real-time, on-the-fly fashion, based on just a handful of examples (e.g., five) provided by a human user. To do so, we leverage metric-based few-shot learning techniques [3, 4] to learn a discriminative embedding space that can generate a robust representation for an unseen novel class based on a few examples. We applied the trained few-shot learning models to various tasks in different audio domains including keyword spotting [5], drum transcription [6], large vocabulary audio tagging [7], and musical source separation [8].

Extracting pitch information from music recordings is a challenging and essential problem in music signal processing. Frame-wise transcription or multi-pitch estimation aims for detecting the simultaneous activity of pitches in polyphonic music recordings and has recently seen significant improvements thanks to deep-learning techniques, with a variety of proposed network architectures. In a recent study [1], we tested different architectures based on convolutional neural networks, the U-net structure, and self-attention components, also proposing several modifications to those. When comparing variants of these architectures with varying capacity using the MusicNet dataset [2], we observed the following:

• $\mathrm{■}$

  Most architectures yield competitive results, and larger model variants seem to be beneficial.

• $\mathrm{■}$

  These results substantially depend on randomness in parameter initialization, data augmentation, order of training examples, and dropout.

• $\mathrm{■}$

  In our cross-version evaluation, where we exploit that our dataset contains several performances (or versions) of each musical work, the particular choice of the training–test splits has a crucial influence on the results.

Concluding from these observations, we question the claim of superiority (“state-of-the-art”) for particular architectures given only small improvements in many published results. To approach these problems, we suggest to shift the focus from technical design choices (such as network architectures) to the more general aspects of experimental design, validity, and generalization with a particular consideration of music-specific properties in the datasets.

In our group discussion, we identified a multitude of ways how musical knowledge could be incorporated into deep learning (DL) models. Almost all system design choices are, or can be informed by understanding the problem domain, including training data, augmentations, invariances, conditioning, representations, features, model architectures, loss functions and evaluation metrics. We then debated whether knowledge integration is a useful or necessary strategy, and how its influence and success could be measured. We noted the difficulty of discussing the topic without reference to one or more specific tasks. Unlike in other fields, where domain knowledge is grounded on physical objects, music is an abstract art form where musical concepts are often hard to grasp. In our discussion, going beyond Western music theory, we attempted to define musical knowledge broadly, covering general (perceptually motivated) concepts such as expectation and surprise. We agreed that musical knowledge can be used as an inductive bias to favour musically likely outcomes, but it remained unclear how one could demonstrate that this bias is more useful (or fair) than the natural biases of the datasets used. Furthermore, we identified example cases where musical knowledge has proven beneficial, and we mentioned HCQT as an input representation, music language models in transcription, and prior knowledge of instrumentation of the input data when performing source separation. We also discussed the potential reduction in training data requirements as an advantage of using domain knowledge, and thus in computational cost. Energy metrics would be one way to demonstrate this advantage, as a contribution to Green AI.

In this working group, we discussed the question of knowledge integration for deep-learning systems in music information retrieval. First, we asked ourselves where and how to integrate knowledge: typical points of leverage can be the dataset creation, the input representation, the network architecture, the loss, or data augmentation strategies. Moreover, knowledge integration at the front-end side (signal processing knowledge) can have different effects than that at the back-end side (musicological or user knowledge). Having an interpretable intermediate representation can help to understand the behavior for downstream tasks as shown for music auto-tagging [1]. Whether knowledge integration is beneficial depends on the desired application, which can be categorized according to various dimensions such as level of expertise or type of task (generation or analysis). For instance, unexpected behavior of an end-to-end system might be considered valuable (“creative”) for music generation. We then turned to an in-depth discussion about the benefits of knowledge integration instead of end-to-end learning. On the one hand, end-to-end systems have shown to be superior to systems integrating knowledge in fields such as computer vision. Moreover, the question arises whether integrating knowledge always leads to a bias. For instance, an input representation relying on the harmonic series will bias results towards music with harmonic instruments and may not work well with inharmonic instruments such as bells, gongs, or low piano notes. On the other hand, such a bias or characteristic behavior may be desired when targeting specific application scenarios. In this sense, knowledge integration can help make a generation system more controllable or an analysis system more objective, interpretable, or plausible. In particular, an analysis system with a human in the loop can greatly use musical knowledge for the reasons mentioned above. Furthermore, all participants agreed that knowledge integration has a high potential to account for smaller and more efficient networks, which helps to move forward towards “Green AI” without losing performance. Finally, touching upon questions raised in the earlier stimulus talks and panel discussions, we agreed that evaluation of model performance is tricky for the case of music information retrieval. Dataset size, annotation quality, annotator bias, and problematic evaluation metrics often limit the validity of experiments, especially given the small-scale improvements usually reported for novel systems. If we consider today’s results in various MIR tasks to be close to a certain upper bound or “glass ceiling,” the main value of knowledge integration may be getting to this upper bound in a more resource-efficient and interpretable way.
