Power and Energy-Aware Computing on Heterogeneous Systems (PEACHES)

Since the breakdown of Dennard scaling, modern CPUs have become power limited to the point where they have to reduce their frequency when executing power-intensive code. This behavior poses a problem for performance isolation: When one task executes power-intensive instructions such as AVX2 or AVX-512, the resulting frequency reduction often affects other less power-intensive tasks.

We propose modifying the CPU accounting of existing fair schedulers to counteract this performance impact. We allocate more CPU time to low-power tasks according to the frequency reduction during execution of these tasks. While the resulting scheduling policy greatly improves performance isolation for many workloads, some workloads present a challenge as the CPU does not provide sufficient information on the power characteristics of individual tasks.

As we are running into a global energy crisis, saving energy in ICT is more important than ever. However, today we just patch security on top of system designs – an approach that inherently introduces performance and energy overheads. The Meltdown patch alone caused performance overheads of roughly 5%, meaning an overhead on greenhouse-gas emissions of up to 0.09% in 2018, a similar single patch in 2030, would cause an overhead of up to 0.4%. This is unsustainable and forces us to rethink security and question how we design systems. In the talk, we argue that the curve we use to optimize systems goes from reliable to unreliable to completely unusable where the system freezes and crashes so frequently that it is not useful for any task. We then argue that we need to rethink how we approach these problems and introduce cryptography-grade error detection combined with correction mechanisms to adjust this curve to make it continuous such that optimizing too far leads only to a loss in performance but never to an uncorrected system error or silent data corruption. If we achieve this, we can optimize for the sweet spot of system efficiency, that has been far out of our reach so far, and while increasing the security of the system.

Operating systems offer numerous configuration parameters to tune the system behavior in general and the energy efficiency in particular. One keystone for an energy-efficient system is the right configuration tailored to the currently running application. Finding the right configuration, however, proves a challenging task. We independently pursued and developed two different approaches, Polar and memutil, to automatically find such an energy-efficient configuration.

Polar is based on a neural network receiving the application profile as input and provides an energy-efficient configuration as output. With this blackbox approach we found that the average energy efficiency (in terms of the energy delay-squared) can be improved by 11.5% for typical applications.

In an independent work, we implemented memutil – a Linux CPU frequency governor – automatically adapting each core’s clock frequency based on live readings from performance measurement units. The most promising heuristic we found to cut idling cycles on high clock frequencies was the number of L2 cache misses. Using a linear frequency interpolation, memutil reduces reduce the energy demand of all tested benchmarks compared to the default governor at minimal execution time penalty of all tested benchmarks from the NPB suite compared to the default.

Although started with different assumptions and application scenarios Polar and memutil show comparable insights and foster future investigation and collaboration.

This talk examines recent work on energy-awareness in sensing systems. This includes both adaptive sampling and adaptive neural networks. Both techniques save energy by adapting execution to inputs or sequences of inputs. Adapting sampling reduces energy by intelligently determining when to take a sample, saving energy through reduced usage of both sensor and radio. Adaptive neural networks save energy by exiting the network early when additional computation is unlikely to affect accuracy.

Unfortunately, both approaches leak information about the inputs (i.e., to either the sensor or the neural network). This talk is meant to spur discussions about these privacy/energy tradeoffs and discuss potential solutions to the problem.

Energy-awareness has become an important topic and has been addressed by researchers working at various levels of the system stack. Energy-aware solutions adjust parameters at their level of the stack to meet energy constraints or optimize energy efficiency. It has recently been observed that solutions working at different levels can interfere with each other, reducing both performance and energy efficiency. One solution for this interference is preventing individual solutions and instead having a central energy-aware authority that manages the options available at all levels simultaneously.

This talk highlights the benefits of coordinating energy-aware solutions across the system stack. It also points out drawbacks of existing, centralized approaches (e.g., [2, 1, 3, 4]). It then highlights several challenges to be addressed to achieve a modular, interoperative, and composable energy-aware system stack.

Software mitigations of hardware vulnerabilities come with costs in terms of runtime and energy. Especially, when an application heavily interacts with the operating system, the mitigation-induced costs can exceed 25% for the Meltdown and Spectre vulnerabilities. Similar results can be observed when disabling SMT/Hyperthreading to mitigate, for example, Microarchitectural Data Sampling (MDS) cross-HyperThread attacks. Hence, it is worth to analyse on the one side whether an application requires the full protection by the mitigations and if not disable them dynamically. On the other side the appropriate mitigation can be selected depending on the current hardware platform and system state for which we propose an approach. So questions that remain are:

• $\mathrm{■}$

  What are the potentials for such an approach?

• $\mathrm{■}$

  How to determine the protection requirements of an application?

• $\mathrm{■}$

  Who’s in control?

• $\mathrm{■}$

  Is it beneficial to move the configuration from hardware into the operating system?

Today, the ICT industry has a massive carbon footprint (a few percent of the worldwide emissions) and one of the fastest growth rates. The Internet accounts for a large part of that footprint while being also energy inefficient; i.e., the total energy cost per byte transmitted is very high. Thankfully, there are many ways to improve on the current status; we discuss two relatively unexplored directions in this paper. Putting network devices to “sleep,” i.e., turning them off, is known to be an efficient vector to save energy; we argue that harvesting this potential requires new routing protocols, better suited to devices switching on/off often, and revising the corresponding hardware/software co-design. Moreover, we can reduce the embodied carbon footprint by using networking hardware longer, and we argue that this could even be beneficial for reliability! We sketch our first ideas in these directions and outline practical challenges that we (as a community) need to address to make the Internet more sustainable.

First steps to address the challenge of sustainable computing are naturally to consider the energy efficiency of information and communication technologies (ICT) during their use phase (i.e., after they are deployed into service). This includes reducing energy consumption in processors, memory systems, peripheral devices, cooling systems and a host of other components that are used in deployed systems. However, for computing to be truly sustainable, all phases of the system life-cycle, from manufacturing to disposal, must be considered. In particular, there is limited awareness to the considerable fraction of the total life-cycle from “embodied” energy and carbon impacts of computing systems from the fabrication of the integrated circuits (ICs) that are used in those devices. These impacts can be predicted from “life-cycle assessment” techniques. Using tools like GreenChip it is possible to holistically evaluate energy consumption and other environmental impacts from computing. Using these tools, I show examples of how machine learning applications and in-memory compression can impact design choices for systems. From this we can find disruptive new ways to think about sustainability and even conservation when designing next generation ICT.

The task scheduler decides when each task will run, and on which core, and thus can impact the machine energy consumption. In the context of large Intel servers (the case of a 2-socket Intel 5218 was illustrated in the talk), we first observe that making the machine fully idle saves more energy than leaving one thread running somewhere on the machine, due to the ensuing uncore costs. Thus, running an application faster, to finish sooner, may reduce energy consumption. We thus present the Nest scheduler, published at EuroSys 2022 [1], that concentrates tasks on a minimal number of cores. Nest make these cores show higher utilization and thus achieve higher core frequencies, causing the application to finish sooner. Finally, we next study schedutil, Linux’s new power governor for reducing energy consumption, and illustrate how, on tasks that frequently sleep for short periods of time due to synchronization, it greatly increases execution time without saving energy. We then wonder how to move forward. Should the operating system impose strategies that impact energy consumption on the hardware, which does not seem to be very successful in the schedutil case, or should it try to work with hardware features, as in Nest?

Federated Learning is a distributed machine learning technique focused on data privacy and security. In a nutshell, Federated Learning involves a group of heterogeneous devices working together to iteratively train a machine learning model under the coordination of a central server. The server chooses a subset of devices for training and sends them the model’s weights for the round. These devices train the model with their own data (which is never shared) and send the updated weights to the server, which averages them before the next training round. The energy consumption of Federated Learning devices is a subject of interest both for environmental reasons and due to the limited energy available on battery-powered devices. In this context, this talk discussed some of the efforts behind performance and energy optimizations on Federated Learning models, including a new idea for an optimal scheduling algorithm for minimizing the energy consumption of Federated Learning devices when controlling how much data each device should use for training.

This talk focuses on power and energy control for cloud and high-performance computing facilities. It promotes hierarchical control systems dynamically adapting to application characteristics in a multi-tenant environment. Controls need to coordinate constraints at application/job level as well as center level to balance multiple objectives while exploiting heterogeneous memory and compute resources to the best of their ability. This leads to a number of challenges with open problems regarding trade-offs between objectives such as energy, performance, QoS, sustainability and profitability subject to future work.

This talk proposes to build and evaluate a power control plane (PCP) for NextG data centers that operate under tight and variable power envelopes. PCP can control power demand at a fine granularity and over short timescales by making it software-defined. The key is to gracefully trade off power and quality of service over time. This allows PCP to shed or consolidate load to less power-intensive processors to conserve power during a power event. I show a prototype power resilient distributed file system (DFS) that establishes the viability of the idea. The DFS provides low-latency fail-over and recovery for load shedding events enabling fine-grained load control by PCP. I outline the important research questions that must be answered for PCP to become practical.

This abstract deals with the recently launched projects NEON (non-volatility in energy-aware operating systems) and PAVE (power-fail aware byte-addressable virtual non-volatile memory), both of which have byte-addressable non-volatile main memory (NVRAM) at their core. Motivation is, on the NEON side, an energy-aware operation of a computing system by using modern NVRAM technology for the operating system itself, namely (1) to save power and (2) to survive power failures, and, on the PAVE side, an operating-system abstraction that should pave the way for a scalable and fail-safe execution of programs (esp. legacy software) virtually directly in NVRAM.

An advantage of the emerging NVRAM technology is the ability to eliminate the need for conventional persistence measures within an operating system and the thus resulting reduction in its space, time and energy requirements as well as a smaller attack surface. Further benefits of NVRAM are its higher speed compared to conventional storage, its rather high capacity compared to conventional DRAM and its ability to keep its state persistently without energy costs.

Unfortunately, today’s CPU cannot (yet) do without volatile memory when registers and caches are considered. Furthermore, NVRAM is much slower than conventional main memory technology such as DRAM and changing the persistent state in NVRAM by writing results in more power consumption than corresponding state changes in DRAM [2]. In addition, fail-safe guarantees are now required from the system, since power failures when writing to the NVRAM, for example, can lead to control flows that unexpectedly convert a sequential process into a non-sequential one [3]. These problems can be solved by an operating system by (1) a suitable event-based, sporadically triggered checkpointing mechanism integrated in its exception- handling subsystem and (2) a suitable integration of NVRAM into the memory hierarchy via its virtual-memory subsystem.

The idea is that a trap or power failure interrupt (PFI) results in a micro-checkpoint request that is handled with strict time guarantee in the operating system: This checkpoint event basically preempts the running process from its volatile environment into the NVRAM. The specified residual energy window as a characteristic feature of the power-supply unit (PSU) determines the upper time limit for this procedure [1], the worst-case execution time (WCET) of which must never exceed it. In program areas where this mechanism cannot be used, particularly for the backup procedure itself, transactional programming comes into play.

A main problem are non-maskable interrupt (NMI) nesting and critical sections that block an interrupt request (IRQ): both endanger the timely handling of a possible checkpoint request. Respective sections are localised by static program analysis and then rearranged based on program transformation tools so that IRQ locks are either eliminated or at least canceled again in good time. This measure ultimately allows also the intended elimination of the persistence measures in the operating system that are superfluous due to NVRAM. For memory-hierarchy integration appropriate is a two-level hierarchy of software-managed caches that uses NVRAM as a buffer for data in conventional storage and DRAM as a buffer for NVRAM pages. The buffering of the pages in the DRAM is subject to strict time guarantees so that this logically persistent data can be reliably consolidated in the NVRAM again in exceptional cases. That is, in order to survive power failures, the maximum size of this DRAM page cache is to be aligned to the size of the remaining energy window in the power supply. Last but not least, energetic methods are designed that improve the mutual interaction of the operating system and NVRAM in such a way that the persistence properties of NVRAM are used to increase energy efficiency. Static NVRAM sleep modes are provided that actively reduce power consumption orthogonally to dynamic runtime improvements by NVRAM governors in the operating system.

In summary, the starting point of both projects is existing knowledge about NVRAM-based persistence of intermittently powered mobile devices on the one hand and persistence measures in stationary computing systems on the other. The basic assumption is that an NVRAM-based operating system manages computing more efficiently than a functionally identical DRAM-based twin. Subject of the study is the specific relationship between energy efficiency, computing power and latency in operating-system variants based on Linux, as far as NEON is concerned, and NVRAM-based capacity scaling and NVRAM virtualisation in FreeBSD, as PAVE contribution. Building on this, the general relationship in terms of applicability, transferability, and generalisation of the techniques developed for NEON and PAVE are examined.

This work is funded by the Deutsche Forschungsgemeinschaft (DFG, German Research Foundation) under Individual Research Grants 465958100 (NEON), 501993201 (PAVE), and 502228341 (Memento) as part of the Priority Programme on Disruptive Memory Technologies (SPP 2377).

The next wave of cloud computing – the serverless computing model – is enjoying adoption at scale by different cloud computing vendors. The serverless computing model is already rapidly accelerating the development and deployment of enterprise applications. Unfortunately, the HPC community appears to be left behind in the revolution and it is not clear what are the energy implications/opportunities for HPC community if they adopted the serverless computing model. First, I’ll discuss how HPC applications and workflows could attain higher performance and energy efficiency via hybrid execution [1, Mashup]. Second, I’ll demonstrate how we can leverage server heterogeneity to reduce the overall energy consumption [2, IcBreaker]. Finally, I will discuss some predictive techniques to mitigate the bottlenecks of serverless computing [3, DayDream], and a brief introduction to a novel AI-workload dataset to enable carbon/aware, sustainable data center computing efforts [4].

Information & Communication Technologies consume more than 10% of the energy produced on Earth, about twice as much as the aviation industry. According to an article from Nature, this number might rise above 20% by 2030. This talk discussed alternatives that might save the world from the digital revolution without stopping it. We discussed the historical facts that have led us to rely on energy-inefficient computing, the possible paths forward, and necessary actions to revert this. As takeaways we established that computing plays a significant and active role in the present and future environmental challenges facing the world; that much of what we know and rely about computing changed in mid 2000’s; that software, especially parallel software, is now even more important to the course of the digital revolution; and that software operation becomes a key concept to ensure optimisations are not wasted.

In this break-out session we discussed the aspect of Energy optimization and management for Power and Energy-aware Computing on Heterogeneous Systems. Our discussion sought to answer a question: How can we create energy optimal or near optimal software solutions? We propose a classification of open problems and associated challenges to identify relevant energy models such that multiple objectives and constraints like price, security, accuracy, time, memory, number of kernels, flexibility, and energy budget are achieved.

The computer stack has several layers, e.g., a simple stack covers developed applications, compilers creating the binaries which are executed by the operating system managing the hardware. Considering the stack from hardware and upwards; the higher the layer, the greater the abstraction, or seeing it top-down: when a layer provides its results to lower layers, it gives control to the lower layers. While the layered structure reduces complexity of the individual task and allows great flexibility, the layers obfuscate how different actions in one layer cause changes in the system’s energy consumption. In an effort to improve transparency it is increasingly common to have the lower layers provide parameters to higher layers of the stack. However, due to the traditional abstractions, the higher layer may not be aware or take advantage. The aspect of energy transparency over the layers is discussed by another breakout session, so in this session we focus on how we can consider energy optimization and management over the whole system and on identifying open challenges.

Different studies show that individual layers can optimize for energy, however no individual layer can provide energy optimal solutions. Additionally, trying to optimize from several layers at the same time can cause energy inefficiencies; as layers that work without knowledge of the others cause destructive interference [1, 2] . Objectives for the optimization are given by the context and the user; prioritizing wanted effect (the output) to the controller(s). Each layer has different optimization opportunities and while a layer may not be able to find an optimal solution by itself, it may expose “knobs”, i.e., variables, and constraints, e.g., max frequency, to controllers. We expect these variables to be domain dependent and, here, we keep the definition of controllers to a semantic definition where a controller decides the values of the variables. A controller could be a full-stack controller, the next system layers (upwards or downwards), or another type of control that governs the values.

In the following, we propose a general formalization of the Energy Optimization and Management Problem. Let there be a set of metrics (non-functional properties) such as price, security, accuracy, time, latency, memory, flexibility, energy budget, green house gas emissions. Some of these metrics will be objectives and some constraints, and over time their role may change. The different layers of the system expose configuration variables and their constraints. We can then formulate the global optimization problem covering the entire stack in the general form of:

optimize f(metrics, t)       // objective
    subject to               //constraints
    G(variables, t) <= b(t)    // this is a system of inequalities
                               // that express the constraints on
                               // the non-functional properties
                               //  and variable values

In general, energy (or power) could appear as part of the objective function or part of the constraints. For example, embedded systems might want to minimize energy given a target latency [3], while an HPC system might have a power constraint (dictated by the facility) and work to maximize application throughput given that constraint [4, 5]. The decision variables represent options provided by different layers of the stack. For example, the embedded application could expose different configuration variables representing the algorithm to use for detecting targets in a signal, with more accurate algorithms requiring more energy. The HPC system could use voltage and frequency scaling as variables that govern power and performance tradeoffs.

This form is a classical optimization form and can be used to express situations where a single controller is given a complete system model and full knowledge of the system’s knobs, or a distributed approach such as when each layer has a separate controller that optimizes over the limited set of knobs in its domain. It can also express problems that are solved once apriori for a workload, or that are frequently re-solved for dynamic workloads that benefit from the system being tuned over time. Given the complexity of modern computing systems, a centralized controller approach is likely to be intractable, although it can be made tractable by identifying and removing variables that have little or no impact on the objective function, being able to find optimal solutions considering a reduced vertical design space. Depending on the problem, the design space is reduced in different ways, i.e., different parts of the solution are fixed:

1. 1.

   from hardware to solution: given a fixed hardware, how may I write my software to solve a specific task while optimizing for a specified objective?

2. 2.

   from software to platform: given my software, how can I find the hardware and/or software system that enables me to solve my specific task while optimizing for a specified objective?

3. 3.

   HW/SW co-design or co-optimization: given this general scenario for my software solving a class of tasks on a family of platforms, how can I optimize for a specified objective?

Formalizing the problem in this way can help us understand the computational complexity of the optimization problem, as well as reveal how objectives can be incorporated into the application development, e.g., accuracy, and a future challenge lies in finding the best ways to build software that can be optimized for energy.

To enable the use of this formulation in practice, we identified the following open challenges:

1. 1.

   Identifying which variables are important to optimize for a given problem class, e.g., a given application or class of applications, or specific hardware, or family of hardware. The fewer variables exposed, the more tractable the problem. It is important that the exposed variables are the significant ones.

2. 2.

   Developing effective interfaces that allow each layer to expose the variables and receive information from other layers.

3. 3.

   Developing energy models that express the relationship between variables and objectives. We speculate that models could be both white-box models such as sets of equations or black-box learned models.

Despite energy consumption of software being an omnipresent topic of discussion, knowledge about means to measure and quantify that energy demand is less widely spread. Complementing the scientific talks at the PEACHES seminar, a series of three practical sessions was held over the course of several days.

In total, 36 persons took part in this “Green Computing Hackathon”. Participants were given a choice of multiple hardware platforms (Laptops, PCs and various embedded boards), as well as example workloads by the organizers. Alternatively, they were encouraged and supported in using their own hardware and investigating self-provided problems from their own research domains.

The first session started with an introductory talk on measurement facilities, hardware counters and a showcase of software tools like “PinPoint” or “likwid” for retrieving energy and power readings on multiple platforms. Furthermore, good practices and avoidance of common pitfalls in energy measurements were discussed.

Among the workloads and benchmark suites investigated by the participants, the most popular was “heatmap”, a simple round-based convolution simulation. Participants compared the influence of different compiler flags, optimisation levels, parallelization strategies, task sizes, clock frequencies, hardware platforms, and vector extensions, as well as the difference between CPU- and GPU-based implementations.

In an extended session, Alex K. Jones demonstrated the “GreenChip” tool, that estimates the carbon footprint for production and application phases in the lifecycle of chip designs. Taking into account factors such as chip area population, chip operational energy, manufacturing technology node, and power grid mix, the tool is focused on indifference and break-even analyses between alternative design choices.

The participants’ feedback for all three hackathon sessions was overwhelmingly positive and we highly encourage future Dagstuhl Seminars to include comparable hands-on sessions.

Tools used:

• $\mathrm{■}$

  https://github.com/osmhpi/pinpoint

• $\mathrm{■}$

  https://github.com/RRZE-HPC/likwid/wiki/Likwid-Powermeter

• $\mathrm{■}$

  https://github.com/Pitt-Jones-Lab/Greenchip

List of hackathon organizers:
Maja Hanne Kirkeby (Roskilde Universitet), Benedict Herzog, Henriette Hofmeier (Ruhr-Universität Bochum), Max Plauth, Lukas Wenzel, Sven Köhler (Hasso Plattner Institute Potsdam)

Five to ten years in the future, the power landscape will have fundamentally changed. The world will have a high proportion of renewables, with volatile power generation. Impact from climate change will be felt much more directly, with power supply variability due to grid disruption sharply up. Information and communication technology (ICT) will also constitute a much larger fraction of the world’s demand for power, due to the end of Dennard scaling and increasing demand for more computation due to machine learning. In this world, power must be a first-class design constraint for all aspects of the systems design process.

The working group discussed how to achieve better transparency of power supply and demand across the systems hardware and software stack. We ask the question: How can we poke through the entire stack of layers in a compute system to allow relevant energy information to flow across the layers to where it is needed? How can lower layers provide energy use information? How can higher layers communicate performance requirements?

In the “Sustainable Computing” breakout session, we looked beyond energy transparency, management, and optimization (which was the focus of the parallel groups). One of our first conclusion was that the footprint of computing services should become more transparent. With computing services, we also mean the physical products involved, such as servers or smart phones. In this case, footprint is not only limited to energy usage in operation, but extends to energy required to manufacture hardware as well as other sustainability metrics related to manufacturing. The latter includes, for instance, CO2 equivalents or effects on humans, e.g. carcinogens, disability-adjusted life years (DALY), or volatile organic compounds (VOC). Generally speaking, we believe that Life-cycle Assessment (LCA) methods should be more thoroughly applied to computing systems to improve transparency.

The Planetary Health Diet⁶⁶6https://en.wikipedia.org/wiki/Planetary_health_diet is a diet that allows a certain population (10bn by the year 2050) to life without hunger, while respecting earth’s natural resources. Similarly, we came up with an idea to develop a Planetary Digital Diet that governs what a sustainable (and healthy) consumption of digital services would be. Analogous to the grams per day for different food categories (e.g. red meat or vegetables), one could come up with minutes per day for different digital services (e.g. office software on desktop or mobile games). We also applied the “Five R’s of Sustainability” (5Rs) to computing. The idea behind the 5Rs is to provide multiple steps at which we can do something with products before we, in the worst case, put them in a landfill or burn them. Refuse is about avoiding a footprint in the first place, while reduce aims for a lower footprint, if it cannot be avoided. When we reuse, we continue using a product in a way that is different from the original manufacturer’s idea; either because it can no longer be used for its original purpose or we do not need it anymore. Recycle is the (usually lossy and energy-intensive) process of turning the product into pieces and using the pieces to eventually create a new product. Lastly, rot is “giving back to nature”, thereby keeping the resources in our ecosystem. Applied to computing, we came up with:

• $\mathrm{■}$

  Refuse: How can users that care about sustainability refuse digital services that would increase their footprint? Which analogue solutions are more sustainable than digital equivalents? How can we stop providers from offering free-of-charge, unlimited services? How can data minimization policies, e.g. GDPR, have a positive sustainability impact?

• $\mathrm{■}$

  Reduce: How can we nudge users to reduce their consumption of digital services (and hence, reduce their footprint)? How can existing and upcoming technology be altered to be more sustainable?

• $\mathrm{■}$

  Reuse: How can we foster the reuse of software instead of reproducing it? How can software be easily reduced in footprint (debloated)? How can software be designed to be easily reusable? How can we foster the reuse of data and models, in particular via open science/source? How can we enable a second life for (more) hardware (analogous to car batteries being reused in stationary contexts)?

• $\mathrm{■}$

  Recycle: How can computing hardware be changed to allow for better decomposition, allowing reparation and recycling of individual components?

• $\mathrm{■}$

  Rot: How can computing systems be build in a biodegradable way? How can renewable materials be used to build hardware?

In summary, we can conclude that there are various steps to be taken to make computing software and hardware more sustainable as well as educate users in sustainable consumption. These steps, in synergy with improving energy-usage that our digital services rely on, can help to create a more sustainable digital future.
