AI-Augmented Facilities: Bridging Experiment and Simulation with ML

The pace of data generation in modern science has greatly accelerated, but the pace of transformational discovery is still too slow. This is clear at a variety of state-of-the-art facilities: laser experiments are slow or noisy; advanced manufacturing (AM) is open loop; accelerators need time consuming tuning, sometimes by hand. However, AI-enable self-driving systems can accelerate our science and discovery processes. AI sentinels that help collect data, compare to prediction, and choose next steps can provide a step change in experimental and manufacturing operations. They will bring accelerated closed-loop operations, transformational data rates, physics-informed experiment updates on sub-second timescales, and digital twins for facility modeling and optimization. This not only accelerates discovery, but it deepens the quality of knowledge that we can discover. As examples, it will provide stabilized lasers and autonomous optimization of high-energy-density physics, self-correcting AM processes and high-throughput operations, and repeatable, robust accelerator conditions. Beyond individual systems, self-driving ecosystems composed of interconnected sets of these facilities will offer capabilities greater than the sum of their parts offering rapid discoveries that are hard to conceive in today’s slower and isolated science regime. To achieve this goal, the science community needs to work together to build the scientific tools to execute self-driving operations. With community input, like that provided by Dagstuhl, we can make self-driving science systems a reality.

In the EU, the use of AI at large-scale research infrastructures is on the rise in a broad variety of fields from Particle Physics to Photon Science, Neutron Science, Life Science, Astrophysics to Laser Science and more. The ESFRI Roadmap and the EU digitalization strategy highlight the importance of data and meta data and the potential of AI. Focusing on the example of Germany, We highlight how the Helmholtz Association as the largest research organization in Europe and in particular the Helmholtz Research Field Matter plan to develop autonomous, intelligent facilities using AI at key points in the data lifecycle of research facilities. The topic Data Management & Analysis and the Helmholtz Incubator for Information and Data Science play key roles, looking at such diverse topics as data lifecycle management, the tight integration of simulation, experiments and machines, online and large-scale data analysis, visual analytics, optimization, automation and resilience. Embedded in a national AI strategy with key components such as the National Research Data Infrastructure, ErUM-Data and many more, embedded in EU-wide and international cooperations and initiatives, the landscape of AI-augmented facilities is being shaped into a EU-wide, cross-community effort to enable excellent science at optimum conditions across the whole spectrum of research infrastructures. We argue that this can be a blueprint for international collaboration on AI-augmented facilities.

In two closely related sessions on Monday afternoon all seminar participants first collected a list of prototypical science drivers that motivate the need for AI-augmented facilities. Subsequently, this discussion branched out to list stakeholders and specific applications that could be used later as examples. Finally, the discussion converged on defining more the goal of the seminar more explicitly: To collect the insights, existing solutions, and strategic ideas into a perspective paper to be jointly published. Consequently, the remainder of Monday afternoon was spend creating a first paper outline that simultaneously served as a guide for the schedule on Tuesday morning. An overview of the topics discussed is provided in Figure 1 in form of a topic graph.

Following the initial paper outline different groups in parallel started to flesh out individual sections. This started with three parallel breakouts on the overall needs, the approach, and the expected outcomes as the cornerstone of the paper.

Tuesday afternoon developed the paper draft further by exploring the software and hardware needs as well as the necessary changes in large scale facilities. The charges for the different group after the morning discussions were as follows:

• $\mathrm{■}$

  Software needs

  • –

    AI techniques and software tools (classes of AI tools – huge networks, tiny ones, …)

  • –

    Orchestration for computing and experiment interoperation

  • –

    More …

• $\mathrm{■}$

  Computing hardware

  • –

    Needs for compute on the instrument

  • –

    Needs for compute at the edge or facility

  • –

    Needs for data center

  • –

    Needs for distributed computing

  • –

    Kinds of architectures, systems

  • –

    More …

• $\mathrm{■}$

  Facility preparation

  • –

    Making facilities look fully integrated – unified compute and experiment

  • –

    Making facilities AI ready (AI ready diagnostics and instruments)

  • –

    Making facilities prepared for computing

  • –

    Making facilities networked to resources

Wednesday morning focused on some outstanding topics such as communication, first steps, and potential early demonstration targets.

The pace and quality of scientific discovery can be greatly improved by erasing the boundary between experimentation and computation. Each step in the scientific process can be revisited with newer hypotheses through the application of machine learning to accelerate scientific discovery, which then enables orchestration of the whole activity. The scientist is then the conductor of this orchestra, and is placed back in control of the increasing complexity and huge scale of modern science.

Coupling scientific computing with large-scale experimentation using modern AI methods will introduce a new class of unified, AI-augmented facility. In such a facility, AI surrogates can be used to capture the intricacies of detailed simulations, but in a way that is accessible to experiments in seconds, not hours or months. Such facilities will then have access to simulations as a real-time commodity for informing experiments. Likewise, AI-guided analysis using representation learning can capture and reduce complicated diagnostic information on the fly. This promises to provide distilled and interpretable empirical data back to the computational world, again in moments, not months. AI-driven representations of both computational and experimental science, scientists can decide far more effectively – about the best next simulation to run or the most insightful next experiment to execute. In fact, these decisions can be accelerated and improved by using formal optimization algorithms that exploit compact AI representations to navigate to superior experimental outcomes; the decisions can even be made semi-autonomous or automated, allowing an optimized loop to execute well-informed experiments incredibly rapidly, keeping pace with modern facilities that perform experiments on the timescales of minutes down to milliseconds.

Its tightly AI-coupled components and efficient information processing ecosystem allow for scientific discovery on much shorter timescales than previously imaginable. Likewise, the AI-enabled operating environment simplifies the execution of simulation and experiment. This frees expert users of the previously disconnected facilities to think and innovate rather than labor over job submission, diagnostic data reduction, and similar operational tasks. Furthermore, non-expert users will find access to complicated science machines to have been democratized, allowing these new facilities to serve a far wider range of scientific communities.

We envision the technical roadmap of our AI-enabled facility to be an energy-efficient framework/design/infrastructure driven by novel hardware and software components that are connected together to form a unified system. With a goal to offer an AI-acceleration solution everywhere, newer dedicated AI-hardware will be built to address the need for a variety of commuting fronts on the diagnostic end, near the facility, at a data center and across a distributed compute network. We will also build software for orchestrating a variety of operations in both high performance compute and experiments. Such AI-orchestrated software will provide the necessary infrastructure to drive informed decisions thus enabling newer science. Facilities augmented by AI will also have a modernized strategy for handling volumes of heterogeneous data that carries context from generation until analysis.

AI will be applied at different levels in scientific facilities.

1. 1.

   On a level close to and integrated into e.g. optical sensors AI will be used to directly provide scientific information rather than raw data to the facility. This will not only lead to significantly decreased requirements in bandwidth and data storage but will also drastically speed up the scientific experiment as such.

2. 2.

   On a facility level AI will be used to generate digital twins of the facility and thus to control scientific experiments. This will significantly increase the efficiency of a facility by better coordinating the tools and sensors involved during the experiment.Moreover the status of the facility and its components will be accessible in real-time and predictive maintenance will become more efficient and will increase the availability and safety of the facility. The digital twin of a facility will also allow for the use of virtual sensors making it possible to collect previously not accessible data.

3. 3.

   On an overall level distributed scientific facilities and HPC resources will be merged together into an AI-driven facility. In these facilities AI will be used to orchestrate the experiments. It will not only significantly speed up scientific experiments but will also be used for planning and conducting of experiments. AI will not only perform experiments better, but will conduct better experiments.

In such a new “generative science” completely new scientific questions will emerge and appropriate experiments will be conducted. Scientists will be able to focus on understanding and answering fundamental questions on the basis of an unprecedented quality of scientific experiments and their results.

The software requirements for the AI Augmented Facilities are driven by users and operators of the facilities. In Software Development Life Cycle (SDLC), these processes are typically referred to as stakeholder analysis and requirement analysis. For the purpose of this document, we identified facility operators and scientists using the facilities as stakeholders. This section offers requirement analysis and identities of current methodologies and places where AI can augment and lead to better results.

We assume that AI-Augmented facilities have the following stages, regardless of the scientific domain (whether they are, e.g., photonic or laser or environmental or datacenter facilities) or whether they are centralized or distributed facilities.

1. 1.

   Basic hypothesis or expectation of the scientific outcomes from experiments or data acquisition

2. 2.

   Simulation studies to understand the hypothesis better, and to develop insights into expected results off the potential experiments or data acquisition

3. 3.

   Empirical data/fielding of experiments

4. 4.

   Consolidation and interpretation of the data for developing better understanding or to underpin scientific discoveries

5. 5.

   Tuning or controlling of the data acquisition step for improving the quality of the data

In the contemporary setting, some of these are human-controlled, which may eventually be replaced by an automated system component in the context of an AI-augmented facility. There are a number of challenges here that different stakeholders face here,especially in the absence of any AI-specific capabilities. These include the following:

• $\mathrm{■}$

  Expensive Simulations: The simulations can be a serious bottleneck to the overall progress, especially when they are of high-fidelity in nature, or when high-quality outputs are desirable,

• $\mathrm{■}$

  Divergence between Simulated and Experimental Data: The actual results from the experiments may as well be different to the hypothesis or expected results, owing to a number of reasons

  • –

    Scope-insensitive calibration of the data acquisition instruments or sensors,

  • –

    Incorrect a priori of hypothesis for simulations, and

  • –

    Physical limitations of the data acquisition, such as potential dosage level or acquisition resolution of the detectors.

• $\mathrm{■}$

  Data Analysis and Enhancements: Understanding, interpreting and analyzing the experimental or sensed data, and correlating that with the a priori formed as part of the hypothesis, and

• $\mathrm{■}$

  Feedback-driven Optimal Control of the experimental facility. Optimal and stable control of the instruments are a serious practical challenge, especially in tolerant-sensitive contexts.

On the hardware level we are currently seeing three trends that will radically impact AI augmented facilities in how they are built, operated, and used:

• $\mathrm{■}$

  Modern AI accelerators are moving from data-center-only use towards facility / on-premise systems making both inference and learning capabilities available closer to the data source.

• $\mathrm{■}$

  Convergence of compute and network in the form of SmartSwitches and SmartNICs, which enables processing on the fly and independent of actual location in a decentralized fashion

• $\mathrm{■}$

  Convergence of compute and storage in the form of Near or In Storage Compute, enabling low-latency data processing at the various and distributed storage location.

Figure 4 illustrates the hierarchy of needs for an AI-enhanced, integrated, experimental and compute facility.

• $\mathrm{■}$

  At the top of the hierarchy is the set of primary data inputs from the experiments represented as a set of sensors. The hardware needs here are extremely low-latency, working with single or small number of samples, high data capture rates, and most importantly engagement with a set of custom / bespoke / specialized sensors that have unique demands such as custom analog signaling that requires high-speed analog to digital converters (ADCs), proprietary formats, etc. Some of the key demands for AI at this level are feature extraction, data processing / conditioning, local controletc. Primarily inference tasks. Another class of sensors are those that are deployed in a Size, Weight, and Power (SWaP) constrained environment / facility. Typical examples of these are battery powered and may be geographically distributed (e.g. drones, buoys, …).

• $\mathrm{■}$

  The next level of the hierarchy is the latency-optimized AI-accelerator that is designed for data-fusion of heterogenous, multi-modal data near the input sensors, forming a “near-line” compute capability. These accelerators need to be optimized to process “single samples” of data (i.e. all of the data from a single event / shot / experiment), and cannot afford to batch multiple samples together prior to processing. Another way to think about this is that they need to be optimized for streaming data sets, where decisions and analysis have to be produced for each sample in real-time. [keywords: streaming, real-time, latency-optimized] Primarily focused on AI inference tasks.

• $\mathrm{■}$

  Integrating the output of the real-time sensor streams output from the near-line accelerators are the near-experiment computing resources. These resources are now expected to work with batches of data samples, and start to blend workloads that include both inference of more complex / larger models as well as the training or fine-tuning of existing or new models

• $\mathrm{■}$

  The bottom of the compute hierarchy is anchored by two classes of computing needs / ecosystems: Leadership-class High Performance Computing (LC HPC) aka capability computing and capacity-based High Throughput Computing (HTC) with persistent and elastic services.

  • –

    HPC resources are intended for full-system, monolithic, modeling and simulation (ModSim) jobs and training of large neural networks (e.g. foundation models). They are designed with highly-interconnected accelerators (e.g. GPUs) using proprietary network architectures (InfiniBand, Slingshot, etc.) Traditionally, these are run in a batch-scheduled manner. Additionally, there is a need to establish new HPC system architecture designs that are optimized for traditional modeling and simulation codes (ModSim), AI training and inference workloads, as well as hybrid cognitive simulations (CogSim) workflows. Optimizations for ModSim include accelerators with high-precision data types (64b arithmetic), high cross-section bandwidth networking, and high-bandwidth write-optimized parallel file systems. HPC optimized for AI training and inference will leverage low-precision accelerators, with read-optimized parallel file systems and support for advanced object-stores. CogSim HPC systems will require a blend of both capabilities.

  • –

    HTC resources are designed to serve the needs of many users, models, or data streams. Persistent and elastic services are designed to capture experimental data in real-time with the ability to meet data surges from the experiment. Additionally, they provide the ability to update / refine / fine-tune AI models in the background as new data is captured.

Fundamental shifts needed in the AI-accelerator architecture space:

1. 1.

   Engagement with customized sensors requires AI-accelerators to interface with a myriad of signaling protocols, formats, and data types (including varying precisions). The current state of the practice is to develop custom accelerator sub-systems that are able to funnel the outputs of these sensors into standard AI-accelerators such as GPUs or a specializable systems such as a blended FPGA / AI-accelerator (such as a Xilinx Versal) through a series of customized ADC capture cards, FPGAs and ASICs. These data capture sub-systems can become quite complex and are as unique as the sensors themselves. The emergence of chiplet-based AI accelerator design would enable a fundamental shift in how research teams would be able to interface state of the art AI accelerators with their custom sensors. Chiplet-based architectures offer the promise of allowing multiple vendors to integrate proprietary hardware into unique hardware processes in a timely and affordable manufacturing process. Advances in this field would enable sensor manufacturers and research teams to more easily and efficiently couple SOTA AI accelerator hardware directly (or closely) to their sensors and thus unleash new capabilities that can be exploited at the sensor.

2. 2.

   AI accelerators in the near-line computing regime will need to be tuned for real-time, streaming workloads, where they need to produce inference results on only a single sample of data that contains a large volume of heterogeneous data fields. Frequently these accelerators will need to be able to meet hard latency limits and execute neural network models (inference) with predictable performance characteristics.

3. 3.

   AI-accelerators close to the sensor may need to meet the demands of a Size, Weight, and Power (SWaP) constrained environments. For these systems, the operational cost in terms of inference requests per Watt will be a key design metric.

The first steps include programmatic proof of concept (POC) starter projects that are co-led between the Data Center and Selected Experimental Facilities, community outreach with workshops and centers of excellence along with training and development events such as hackathons.

The POC projects will develop and demonstrate the new workflows that connect the Science Data center with the Experimental facility, where AI is used as part of the workflow that connects them.. An example of a program is the SuperFacility Project at NERSC⁵⁵5https://www.nersc.gov/research-and-development/superfacility/. Each POC project must have scope that is sufficient to demonstrate the potential for improved science and identify features and requirements that can’t be met with the current infrastructure.

A key feature of the new workflows are AI algorithms is that once trained at the HPC Data Center are fast enough and accurate to be deployed at the experiments for control and/or improvement of experiment operation. Another feature is Active Learning that may be executed at the Data Center and/or the experimental facility that can be used in conjunction with experiment operation. Simulation workflows are critical for explainability and validation of AI approaches as well as for generation of synthetic training datasets.

Examples of projects include improving the control of a Fusion Experiment, Multi Messenger Astrophysics, Improving the process for drug discovery with a biology lab or data analysis/evaluation on the fly as a neutron/x-ray/electron/light scattering experiment executes. Key features have already been identified that will need to be acted on in the near term to allow for the new workflow include the following:

• $\mathrm{■}$

  The Data Center Facility will need to include features that allow interactive usage that is interrupt driven along with the current batch oriented usage model for long running jobs.

• $\mathrm{■}$

  Both the Data Center and Experiment will need to be able to support the bandwidth and latency for data transfer. Reconfigurable storage will also be needed to support the experiment as it executes, which acts as a workflow buffer between the storage at the experiment and persistent platform storage at the data center.

• $\mathrm{■}$

  The Experiment hardware/software should allow for automated control. Curated data in the form that it can be used by AI will also be required.

• $\mathrm{■}$

  Funding agencies will need to initiate projects to pursue the new use cases for a sufficient period of time to develop a working example.

Workshops that cross domains as well as specific to a given domain will be needed to promote the new methods, socialize new concepts, identify key requirements and avoid redundancy. Where possible Centers of Excellence, Data Hubs and other vehicles should be developed for concentrated effort on specific projects within a community. The workshops and COEs should be balanced with Hackathons and bootcamps that can serve to help train users on the new tools and approaches. Additionally, hackathons and bootcamps allow for collective efforts to address challenging problems relevant for multiple facilities (inverse problem-related issues, uncertainty quantification, etc.) that result in code that can be evaluated.
