Topological Data Analysis and Applications

Topology is considered one of the most prominent research fields in mathematics. It is concerned with the properties of a space that are preserved under continuous deformations and provides abstract representations of the space and functions defined on the space. The modern field of topological data analysis (TDA) plays an essential role in connecting mathematical theories to practice. It uses stable topological descriptors as summaries of data, separating features from noise in a robust way. The seminar brought together researchers from mathematics, computer science, and application domains (e.g., materials science, neuroscience, and biology) to accelerate emerging research directions and inspire new ones in the field of TDA.

The Dagstuhl Seminars 17292 (July 2017) and 19212 (May 2019) were successful in enabling close interaction between researchers from diverse backgrounds. The attendees consistently remarked about the benefits of building bridges between the two communities. The goals from the previous seminars were to strengthen existing ties, establish new ones, identify challenges that require the two communities to work together, and establish mechanisms for increased communication and transfer of results from one to the other. A key goal of the current seminar was to additionally bring in experts from a few application domains to provide the necessary context for identifying research problems in topological data analysis and visualization. Furthermore, we also encouraged interaction between researchers who worked within the same community to identify challenging problems in the area and to establish new collaborations.

The research topics, listed below, reflect highly active and emerging areas in TDA. They were chosen to span topics in theory, algorithms, and applications.

The invitees were chosen based on their background in mathematics, computer science, and application domains. We also ensured diversity in terms of gender, country or region of workplace, and experience.

While welcoming theoretical talks, the attendees were strongly encouraged to prepare a talk that is rooted in applications. The aim was to foster discussions on topics and projects related to practical applications of topological analysis and visualization. The program for the week consisted of talks of different lengths, breakout sessions, and summary / discussion sessions with all participants. We scheduled a total of six long talks (35 minutes + 10 minutes Q&A) on Day-1 and the morning session of Day-2, each providing an introduction either to one of the four chosen topics of the seminar or to a specific application domain. The talks were given by Yasu Hiraoka (Curse of dimensionality in persistence diagrams), Manish Saggar (Precision dynamical mapping to anchor psychiatric diagnosis into biology), Andreas Ott (Topological data analysis and coronavirus evolution), Kelin Xia (Mathematical AI for molecular data analysis), Gunther Weber (Topological analysis for exascale computing: challenges & approaches), and Facundo Mémoli (Some recent results about Vietoris-Rips persistence). Short research talks (16 total, 15 minutes + 10 minutes Q&A) were scheduled during the morning sessions of Day-2 through Day-5.

The afternoon sessions were devoted to discussions, working groups, and interactions. On Monday, we led an open problem session where participants identified different open problems and future directions for research. This initial discussion helped identify working groups and topics for discussion during the week. We organized breakout sessions on Tuesday and Thursday. On Tuesday, after a quick discussion regarding discussion topics, we identified four topics of interest. Participants chose one of the four groups> the curse of dimensionality, distances on Morse and Morse-Smale complexes, computation of generalized persistence diagrams, Codistortion and Gromov–Hausdorff distance. After a quick discussion, we decided to continue discussions on the four topics on Thursday, and some participants chose to join a different group.

We organized an excursion to Trier on Wednesday afternoon followed by dinner at a restaurant. Many participants attended the guided tour and the dinner.

All working groups summarized the discussion during their breakout sessions and presented it to all participants on Thursday evening and Friday morning. These summary sessions were also interactive and resulted in follow-up discussions between smaller groups of participants. We organized a final discussion and feedback session on Friday morning to close the seminar and to make future plans.

The schedule for the first day helped initiate interaction between participants and continue the discussions during the week. While the introductory talks provided sufficient details on interesting application domains, the open problem session allowed many participants to quickly pose topics of interest. In particular, the format of this session extended beyond proposing specific stated open problems, asking also for contributions, discussion points, and thoughts that would not typically be brought up in such a session. This resulted in a very lively and engaging discussion that encouraged participants to share their perspectives on important current and future research directions.

In summary, we think that the seminar was successful in achieving the objective of encouraging discussions and interaction between researchers with backgrounds in mathematics, computer science, and application domains who are interested in the areas of topological data analysis and visualization. It helped identify new directions for research and has hopefully sparked the engagement of researchers from one community into the activities and research workshops and venues of the other. We strongly believe that the seminar provided a highly valuable contribution to bridging the gap between theory and applications in TDA.

The participants were highly appreciative of the balance between theoretical and applied topics and between the participants and those who presented during the week. They highlighted that the diverse group of participants sharing a strong interest in novel perspectives and exchange of ideas made the workshop an exceptional experience. Several felt that the discussions helped them identify topics for future research or introduced them to new collaboration possibilities.

Topological descriptors such as merge trees and extremum graphs have proven to be very useful for multiscale feature-based analysis of scalar field data. However, in some applications extraction of features is not enough, understanding the separation/topological distance between the extracted features is also important. Intrinsic tree distance can be used to quantify this topological distance. I will talk about two different applications where quantifying feature separation is useful and has physically interpretable meaning. One of the challenges that arise in the context of time-varying or ensemble scalar field data is tracking and visualization of the change in inter-feature separation with the change in time or input parameters. I will present some preliminary ideas and results in this direction.

Several methods for geometric inference relies in the choice of an appropriate metric in the sample point cloud. Consider a scenario where the data is a noisy sample of a manifold embedded in Euclidean space, drawn according to a positive density over the manifold. I propose to learn a metric directly from the data (called *Fermat distance*) that turns out to be an estimator of an intrinsic density-based metric over the underlying manifold. I will show some convergence results, robustness properties of the use of this metric in the computation of persistent homology and some applications in real data. I will also discuss a couple of open questions.

Visualizing vector fields and their impact on free-form surface modelling like car hoods or airplane wings is a hot topic. We can “use” these vector fields to “deform” the metric of these surfaces, generating a Finsler metric. Can such a Finsler metric be useful for vector field visualization?

Persistent homology is well-defined and well studied for tame filtrations, for example various ones arising from finite point sets. However, periodic filtrations – for example used to study periodic point sets, like the atom positions of a crystal – are not tame, because there are infinitely many periodic copies of a homology class appearing at the same filtration value. We therefore extend the definition of persistent homology to periodic filtrations, which is a surprisingly difficult endeavor. In contrast to related work, we quantify how fast the multiplicities of persistence pairs tend to infinity with increasing window size, in a way that is stable under perturbations and invariant under different finite representations of the infinite periodic filtration. This project is still ongoing research, but I’ll explain what we already know and what we don’t know yet.

It is well known that persistence diagrams stably behave under small perturbations to the input data. This is the consequence of stability theorems, firstly proved by Cohen-Steiner, Edelsbrunner, and Harer (2007), and then extended by several researchers. On the other hand, if the input data is realized in a high-dimensional space with a small noise, the curse of dimensionality (CoD) causes serious adverse effects on data analysis, especially leading to inconsistency of distances. In this talk, I will show several examples of CoD appearing in persistence diagrams (e.g., from single-cell RNA sequencing data in biology). Those examples demonstrate that the classical stability theorems are not sufficient to guarantee stable behaviors of persistence diagrams for high-dimensional data. Then I will show several mathematical results about the existence and the (partial) resolution of CoD in persistence diagrams. This is a joint work with Liu Enhao, Yusuke Imoto and Shu Kanazawa.

Topology in visualization – balance between beautiful concepts and practical needs

Tracking of features is a fundamental task in visual data analysis. In our work, we use topological descriptors as an abstraction for tracking. An essential step thereby is the choice of appropriate similarity measures to detect structural changes and establish a correspondence between individual features respecting their spatial embedding. One way to approach both demands is to consider labeled merge trees as the feature descriptor. In this talk, some examples of such approaches for tracking features are discussed.

The density-Rips bifiltration is a standard construction in multi-parameter persistence, but suffers from the size explosion, as its single-parameter counterpart. On the other hand, it is well-known that at least in low Euclidean dimensions, alpha filtrations are much faster to compute and also geometrically more accurate. There are two major challenges to define and compute alpha-filtrations for two parameters. I will propose a way how to handle them. This is (very) ongoing work with Angel Alonso (TU Graz).

In topological data analysis, a function $f:M⟶R$ is often studied through the homology of its sublevel sets. One can obtain a topological summary of $f$ in the form of a persistence barcode [3]. By a result of Morse theory, if $M$ is a closed manifold and $f$ is nice enough, then $M$ is homotopy equivalent to a CW-complex with one $k$-cell for each critical point of index $k$ [5]. Persistent homology and Morse theory are closely related, since the values of f at the critical points are equal to the start- and endpoints of the bars in the barcode. The gradient of f induces a chain complex, where the boundary operator is defined by counting the flow lines between critical points (see e.g. [1]). This process works more generally for gradient-like Morse-Smale vector fields and also for combinatorial vector fields in the sense of Forman [4]. However, for gradient-like Morse-Smale vector fields, there does not yet exist a persistence barcode such as for functions.

We present a pipeline that takes as an input a gradient-like Morse-Smale vector field on a surface, produces a parameterized epimorphic chain complex, and encodes it as a barcode. More precisely, we produce a sequence of chain complexes, such that the first one is the chain complex induced by the vector field and after that, each one is a quotient of the previous one. These quotients correspond to topological simplifications of the vector field by certain moves (introduced in [2]), and the times of taking the quotients depend on the value of a parameter measuring the local robustness of the vector field. In the end we are left with a vector field that has a very simple topological structure. Geometrically, for each move that is applied, we extract a topological feature. Algebraically, for each quotient, we split off an indecomposable contractible summand from the initial chain complex. Remembering the times when the moves were applied then yields a barcode. Similarly to the usual persistent homology construction for real valued functions, this pipeline paves the way for the development of a theory of persistence for vector fields.

Let $ℳ$ be the collection of compact metric spaces. The Gromov–Hausdorff distance between $(X,d_X)$ and $(Y,d_Y)$ in $ℳ$ is defined as

where

are the distortion of a map and the codistortion of a pair of maps between metric spaces, respectively. Separating the distortion and codistortion terms in this formula for the Gromov–Hausdorff distance, we obtain the variants

Clearly ${\widehat{d}}_{\text{GH}},{\check{d}}_{\text{GH}}\le d_{\text{GH}}$. The following facts about the distortion distance ${\widehat{d}}_{\text{GH}}$ are known. Below $\cong$ denotes the equivalence relation of isometry on $ℳ$.

1. 1.

   ${\widehat{d}}_{\text{GH}}$ is a legit distance on the set of isometry classes of compact metric spaces $ℳ/\cong$.

2. 2.

   ${\widehat{d}}_{\text{GH}}$ and $d_{\text{GH}}$ generate the same topology.

3. 3.

   ${\widehat{d}}_{\text{GH}}\ne d_{\text{GH}}$.

4. 4.

   ${\widehat{d}}_{\text{GH}}$ can be computed via curvature sets.

Less is known about the codistortion distance ${\check{d}}_{\text{GH}}$. We state a few interesting questions.

1. 1.

   Is ${\check{d}}_{\text{GH}}$ a distance on $ℳ/\cong$?

2. 2.

   Is ${\check{d}}_{\text{GH}}$ bi-Lipschitz equivalent to $d_{\text{GH}}$?

In our discussion group, we answered these questions to the affirmative.

The following lemma is key to relating distortion and codistortion.

The stability result of Persistent Homology is not guaranteeing much in very high dimensions, when noise of at most $\epsilon$ is added in each dimension to the data. Indeed, the ${\mathrm{\ell }}_2$-distance between a point $x\in {ℝ}^d$ and its perturbed point $x+p$ with is ${\Vert p\Vert }_{{\mathrm{\ell }}_2}\le \sqrt{d}\epsilon$. Hence, the stability bound, namely the Hausdorff distance between the original and the perturbed point set, is $O(\sqrt{d}\epsilon )$ as well.

We prove that this effect, the curse of dimensionality, cannot be circumvented in full generality, i.e., when an adversary is allowed to make the choices. This shows that we need some assumption on the data. We list some ideas for possible assumptions, and approaches that seem promising within these different assumptions.

One breakout session was focused loosely on understanding the problem of computing generalized persistence diagrams (GPDs), as defined by Kim and Mémoli.

Given a poset $P$, persistence module $M:P\to \mathrm{Vec}$, and a generalized interval (a.k.a. spread) $I\subset P$, the generalized rank of $M$ over $I$ is the rank of the map

The map sending each such $I$ to its generalized rank is the generalized rank invariant (GRI) of $M$. Taking the Möbius inversion of the GRI yields the generalized persistence diagram (GPD), a kind of signed barcode for generalized persistence.

Signed barcodes have become a hot topic in TDA in the last few years. There are multiple ways to define a signed barcode, namely, by taking Möbius inversions of different functions, or by relative homological algebra with respect to different exact structures.

Among the various options, the GPD studied here is an appealing choice because it is a relatively rich invariant and also has a very simple interpretation in the case of spread-decomposable modules: On such modules, the GPD simply counts the number of copies of each spread in the decomposition. In contrast, other types of signed barcodes can be rather complicated on such modules. This makes the problem of computing the GPD interesting. This problem is mostly open, in spite of some interesting recent work by Dey, Kim, Mémoli on the related problem of computing the GRI at fixed indices.

Our group explored (in a very preliminary way), the following related questions:

• $\mathrm{■}$

  What does the GPD look like on specific examples of non-spread decomposable modules? How quickly does its size grow as the support of the module grows.

• $\mathrm{■}$

  In the special case that $M$ has a small encoding in the sense of Ezra Miller’s work (i.e., there exists a surjection of posets $f:P\to Q$ and a functor $N:Q\to \mathrm{Vec}$ with $f=N\circ g$ and $|Q|$ small), is efficient computation of $M$ possible? How does the complexity of computing the GPD depend on $|Q|$? What bounds on $|Q|$ can be expected in practical 2-parameter persistence computations? How does one compute $f$?

• $\mathrm{■}$

  Can the ideas underlying recent work by Morozov and Patel on the output-sensitive computation of signed barcodes for 2-parameter persistence also be useful for computing GPDs?

There was some progress made. The first example we looked at was

We made an attempt to understand if a module was nearly interval indecomposable, how complex could the generalized rank invariant be. Under the appropriate choice of morphisms, the above decomposes into many non-trivial pieces in the generalized rank invariant.

Following up on this, there was also a discussion on whether such non-interval indecomposables occur in practice/arises in random settings, e.g. from random point clouds. Michael Kerber suggested a bifiltration example which was finite and the point positions were generic, i.e. a positive but small perturbation does not affect the decomposition. We then showed that this will occur in a uniform Poisson point process with probability 1 as the number of points goes to $\mathrm{\infty }$. The idea behind the proof is that one can define a random variable of the event of such a configuration occurring, i.e. using the small neighborhood of the example. As the configuration is finite and generic, the probability of the event is strictly positive. As the expected number of such neighborhoods goes to $\mathrm{\infty }$, the probability must go to 1. Michael Kerber also reported his experimental results which indeed show that non-interval indecomposables arise in many experiments.

While we did not make decisive progress, the discussions were illuminating and left us with a better understanding of invariants and their computation.

Given $f:ℳ\to ℝ$, the Morse complexes partition $ℳ$ into ascending/descending manifolds of minima/maxima. The Morse-Smale complex is the intersection of the two Morse complexes. Given $f_1$, $f_2$, and their Morse-Smale complexes $MS{C}_1$, $MS{C}_2$, how to define distances or metrics $d(MS{C}_1,MS{C}_2)$? This working group met on two days and focused on brainstorming likely lists of ideas worth pursuing, hopefully sparking ideas for future work in the participants when tackling this difficult and surprisingly open problem.
