Network Calculus

TTEthernet is an Ethernet-based synchronized network technology compliant with the AFDX standard. It supports safety-critical applications by defining different traffic classes: Time-Triggered (TT), Rate-Constrained (RC), and Best-Effort traffic. The synchronization is managed through the AS6802 protocol, which defines so-called Protocol Control Frames (PCFs) to synchronize the local clock of each device. In this presentation, we analyze the synchronization protocol to assess the impact of the PCFs on TT and RC traffic.

We propose a method to decrease the impact of PCFs on TT and a new Network Calculus model to compute RC delay bounds with the influence of both PCF and TT traffic. We finish with a performance evaluation to i) assess the impact of PCFs, ii) show the benefits of our method in terms of reducing the impact of PCFs on TT traffic and iii) prove the necessity of taking the PCF traffic into account to compute correct RC worst-case delays and provide a safe system.

When considering multiple flow scenarios, strictness of service curves is required to obtain a residual service curve for a single flow. Without strictness, the residual service curve exhibits an interval over which it is negative and decreasing, i.e., it is not in ${ℱ}_0^{\uparrow }$ anymore. However, this assumption is needed to calculate performance bounds. Introducing a lower bound on the arrivals to a system, the inherent issue can be avoided.

In our talk, we discuss the issue at hand and show how the existing performance bounds can be adjusted to work with service curves that are not in ${ℱ}_0^{\uparrow }$. We also discuss potential applications.

In this talk, a quick recap on the “Wireless Network Calculus” talk at Dagstuhl Seminar 15112 on Network Calculus is first provided. Then, the focus is on introducing some fundamental advances in the topic since that talk. They include the light-tailed property of wireless channel capacity, the dependence structure and copula analysis of wireless channel capacity, and Spatial Network Calculus for wireless networks. The third part is devoted to reliable performance, e.g. 99% packet delivery ratio, in wireless mesh or massive machine-type communications (mMTC). Experimental results from real word IoT wireless networks are used to demonstrate that there is a huge gap. To bridge, an idea is introduced at the end. It is to coordinate transmission among nodes such that the transmission nodes satisfy certain constraints with which the required reliability can be ensured from Spatial Network Calculus analysis.

Main references for further reading:

• $\mathrm{■}$

  F. Sun and Y. Jiang. A Statistical Property of Wireless Channel Capacity: Theory and Application. IFIP Performance 2017

• $\mathrm{■}$

  F. Sun and Y. Jiang. Stochastic Dependence in Wireless Channel Capacity: A Hidden Resource. arXiv 1711.10363 (2017/2019)

• $\mathrm{■}$

  K. Feng and F. Baccelli. Spatial Network Calculus and Performance Guarantees in Wireless Networks. IEEE Trans. Wireless Communications. 23(5): 5033-5047 (2024)

Time Sensitive Networks offer guarantees on worst-case delay, worst-case delay variation and zero congestion loss; in addition, they provides mechanisms for packet duplication in order to hide residual losses due to transmission errors. They find applications in many areas such as factory automation, embedded and vehicular networks, audio-visual studio networks, and in the front-hauls of cellular wireless networks. In this talk we describe recent network-calculus results that can be used to analyze time sensitive networks with components such as packet ordering and duplicate removal functions, schedulers, regulators, dampers. We explain why clock non-idealities matter and how to take them into account.

Models for the dynamics of congestion control generally involve systems of coupled differential equations which assume that traffic sources saturate the maximum transmissions allowed by the congestion control method. This is not suitable for studying congestion control of intermittent but bursty traffic sources. In this talk, we presented a characterization of congestion control for arbitrary time-varying traffic that applies to rate-based as well as window-based congestion control. We leverage the capability of network calculus to precisely describe the input-output relationship at network elements for arbitrary source traffic and show that our characterization can closely track the dynamics of even complex congestion control algorithms.

Resource reservation is a fundamental mechanism for ensuring quality of service in time-sensitive networks. In the Ethernet technology Time-Sensitive Networking, this can be done decentrally through new resource reservation protocols. For reservation, the standards assume a maximum worst-case latency that is limited at each hop. However, we show that these worst-case latency bounds are not safe. To address this, we propose an alternative to the current standards to allow reservation of time-sensitive traffic with reliable latency guarantees, using Network Calculus. The talk is based on a publication for the Credit-Based Shaper forwarding mechanism, but extends that work to generalise the solution for different forwarding mechanisms and to determine the forwarding parameters, such as the reserved bandwidth.

This work contributes tail bounds of the age-of-information of a general class of parallel systems and explores their potential. Parallel systems arise in relevant cases, such as in multi-band mobile networks, multi-technology wireless access, or multi-path protocols, just to name a few. Typically, control over each communication channel is limited, and random service outages and congestion cause buffering that impairs the age-of- information. The parallel use of independent channels promises a remedy, since outages on one channel may be compensated for by another. Surprisingly, for the well-known case of M|M|1 queues we find the opposite: pooling capacity in one channel performs better than a parallel system with the same total capacity. A generalization is not possible since there are no solutions for other types of parallel queues at hand. In this work, we prove a dual representation of age-of-information in min-plus algebra that connects to queueing models known from the theory of effective bandwidth/capacity and stochastic network calculus. Exploiting these methods, we derive tail bounds of the age-of-information of G|G|1 queues. Tail bounds of the age-of-information of independent parallel queues follow readily. In addition to parallel classical queues, we investigate Markov channels where, depending on the memory of the channel, we show the true advantage of parallel systems. We continue to investigate this new finding and provide insight into when capacity should be pooled in one channel or when independent parallel channels perform better. We complement our analysis with simulation results and evaluate different update policies, scheduling policies, and the use of heterogeneous channels that are most relevant for the latest multi-band networks.

Total Flow Analysis (TFA) is a method for conducting the worst-case analysis of time sensitive networks without cyclic dependencies. In networks with cyclic dependencies, Fixed-Point TFA introduces artificial cuts, analyses the resulting cycle-free network with TFA, and iterates. If it converges, it does provide valid performance bounds. In the first part of this talk, I show that the choice of the specific cuts used by Fixed-Point TFA does not affect its convergence nor the obtained performance bounds, and that it can be replaced by an alternative algorithm that does not use any cut at all, while still applying to cyclic dependencies. In the second part, I present Saihu, a common python interface for worst-case delay analysis. Currently it integrates the 3 most used worst-case network analysis tools : xTFA, DiscoDNC, and Panco. Saihu provides a general interface that enables defining the networks in a single XML or JSON file and executing all tools simultaneously without any adjustment for individual tools. Saihu also exports analysis results into formatted reports automatically. Saihu is modular, allowing other worst-case analysis tools to be integrated in the future.

A key metric to express the timeliness of status updates in latency-sensitive networked systems is the age of information (AoI), i.e., the time elapsed since the generation of the last received informative status message. State-of-the-art approaches to analyzing the AoI rely on queueing models that are composed of one or many queuing systems endowed with service order, e.g., FIFO, LIFO, or last-generated-first-out order. A major difficulty arising in these analysis methods is capturing the AoI under message reordering when the delivery is non-preemptive and non-FIFO, i.e., when messages can overtake each other and the reception of informative messages may obsolete some messages that are underway.

This talk which is based on our work [1] describes the derivation of computable exact formulations for the distribution of AoI in non-preemptive, non-FIFO systems where the main ingredients of our analysis are Palm calculus and time inversion.

In recent years, there has been a trend toward using programs written in high-level domain-specific languages to specify network packet processing behavior. This has opened up possibilities to use program analysis techniques to formally reason about network properties such as reachability and absence of forwarding loops. Most of the existing work in this area focuses on reasoning about the functional correctness of computer networks. In this talk, we present our recent efforts in using logic-based formal analysis techniques to reason about network performance properties such as throughput, latency, starvation, and fairness, and its potential synergies with network calculus. In particular, we discuss (1) how using logic-based formal analysis can help relax some of the assumptions and simplifications one may need to make in network calculus about modeling the arrival pattern of traffic, the packet processing logic, and packet loss, and (2) how network-calculus-like abstractions can help reduce the significant computational overhead that logic-based formal analysis of performance properties is prone to in comparisons with functional-correctness properties.

Experimental modular Total-Flow Analysis (xTFA) is an open-source experimental Python tool for computing end-to-end latencies in time-sensitive networks. Through a modular conception based on computational blocks and flow-state partitions, xTFA supports a wide variety of models, including redundancy functions, interleaved regulators, cyclic dependencies, and clock non-idealities. But the modularity of the tool is limited because of the assumptions that the different models make and the variety of these assumptions. This talk discusses the origin of these limitations and proposes open question towards a classification of assumptions for service-curves properties in time-sensitive networks.

Parallel systems divide jobs into smaller tasks that can be serviced by many workers at the same time. Some parallel systems have blocking barriers that require all of their tasks to start and/or depart in unison. This is true of many parallel Machine Learning workloads, and popular Apache Spark engine has, for this reason, recently added support for Barrier Execution Mode (BEM).

The drawback of these barriers is reduced performance and stability, compared to equivalent non-blocking systems. We derived analytical expressions for the stability for BEM systems and extend results from Network Calculus to derive waiting and sojourn time bounds.

Our results show that for a given utilization ($\rho$) and number of workers ($s$), there is an optimal degree of parallelism ($k$) that balances waiting time and execution time to minimize sojourn times. This complements prior work on so called ”tiny tasks”, where $\frac{k}{s}>>1$, to show that among systems with barriers, the unstable Split-Merge model ($k=s$) is the anomaly, and taking or $\frac{k}{s}>1$ is actually much better.

In this talk, I present results and work in progress improving the existing software and algorithms for DNC computations, particularly those built on the Nancy computational library. First, I discuss the optimizations stemming from the duality between (min,+) and (max,+), which we call isospeed algorithms. Then, I present some work in progress that may be useful to the community: Nancy HTTP wrappers, to use the library from other languages; Nancy.Interactive to improve the testing and teaching workflow; Nancy.Expressions, opening up new ways to optimize computations transparently to the user; and DNC Benchmarking, a project aimed at benchmarking DNC implementations to highlight the impact of optimizations on runtime. Finally, a note on the need for practical examples to highlight, especially to those outside our community, where the hard computations are in DNC, and thus improve the chances of publication of this kind of results.

Recent studies have highlighted similarities between different analyses approaches for real-time systems:

• $\mathrm{■}$

  The equivalence between Real-Time Calculus (RTC) and the variable capacity node in Network Calculus (NC) was established over a decade ago.

• $\mathrm{■}$

  More recent research identifies similarities with Response Time Analysis (RTA) and even stream models.

Despite these similarities, significant differences in the approaches remain. Investigating the potential of NC formalism could be beneficial.

The group discussed different versions of service, which offered different points of view (Adaptive service, Real-Time Calculus – RTC, strict service, etc.).

Some discussions also on the equivalence between (min,+) and (max,+) dioids. Rather than using them one at a time, one can think about (min-plus) and (max-plus) at the same time. Starting points can be found in the 1992 book by Baccelli/Cohen/Olsder/Quadrat [1]. Since convolution is a Minkowski sum, an exploration of algebras of Minkowski systems may lead to progress. The Moreau conjugacy a generalisation of legendre transform, has also been mentioned.

We also speak about the question of rare perturbation. The deterministic network calculus is designed to bound the worst case, but not to quantify how rare/frequent are this worst cases. Considering a sequence of message, all having a delay of 1ms except one out of 1000 that have a delay of 10ms. Then network calculus is not able to make the difference with a sequence with all delays being 10ms. And this is not related to the bounding methods, even the definition of delay is not able to capture it.

Additional, short discussion have been done on how to model real systems with notion of mode and mode change and on interesting non-linear systems.
