Revisiting Timing Anomalies in Predictable In-Order Pipelines

Authors Lilia Rouizi , Mihail Asavoae , Benjamin Binder , Lionel Rieg , Florian Brandner

PDF

File

Thumbnail PDF
PDF
LIPIcs.ECRTS.2025.19.pdf
  • Filesize: 1.15 MB
  • 22 pages

Document Identifiers

Subject Classification

ACM Subject Classification
  • Computer systems organization → Architectures
  • Computer systems organization → Real-time systems
Keywords
  • Timing Anomalies
  • Causality
  • Timing Predictability
  • Timing Analysis

Metrics

  • Access Statistics
  • Total Accesses (updated on a weekly basis)
    0
    PDF Downloads
    0
    Metadata Views

Abstract

The quality of timing guarantees ensured through worst-case-execution time analysis and schedulability tests - required to be both sound and precise - is directly influenced by the predictability properties of the execution platform. A platform is considered predictable when safe and precise bounds can be computed through analysis tools. Counter-intuitive and Amplification Timing Anomalies (TAs) are detrimental to predictability and thus may make it much harder/impossible to compute such bounds. In order to address this issue, research has followed two orthogonal approaches, (i) designing predictable execution platforms and (ii) characterizing counter-intuitive TAs through formal definitions. However, predictable designs rarely apply any formal definitions of timing anomalies.
This paper aims at investigating precisely this relationship. We first show how a previously proposed definition of counter-intuitive TAs can be applied to the predictable in-order processor SIC. We then extend this approach in order to provide the first formal definition of both counter-intuitive and amplification effects. The proposed definitions are then evaluated on a regular in-order processor as well as the predictable SIC core using a systematic approach that allows to assess their applicability and relevance. Finally, we prove, for the first time, the absence of some, but not all, TA effects in SIC.

Cite As Get BibTex

Lilia Rouizi, Mihail Asavoae, Benjamin Binder, Lionel Rieg, and Florian Brandner. Revisiting Timing Anomalies in Predictable In-Order Pipelines. In 37th Euromicro Conference on Real-Time Systems (ECRTS 2025). Leibniz International Proceedings in Informatics (LIPIcs), Volume 335, pp. 19:1-19:22, Schloss Dagstuhl – Leibniz-Zentrum für Informatik (2025) https://doi.org/10.4230/LIPIcs.ECRTS.2025.19
