Low-Latency Real-Time Applications on Heterogeneous MPSoCs

Authors Nicolas Coppik , Pascal Becker , Marcus Ritter

PDF
Thumbnail PDF

File

OASIcs.NG-RES.2025.2.pdf
  • Filesize: 0.75 MB
  • 14 pages

Document Identifiers

Author Details

Nicolas Coppik
  • ABB AG Corporate Research Center, Mannheim, Germany
Pascal Becker
  • ABB AG Corporate Research Center, Mannheim, Germany
Marcus Ritter
  • ABB AG Corporate Research Center, Mannheim, Germany

Cite As Get BibTex

Nicolas Coppik, Pascal Becker, and Marcus Ritter. Low-Latency Real-Time Applications on Heterogeneous MPSoCs. In Sixth Workshop on Next Generation Real-Time Embedded Systems (NG-RES 2025). Open Access Series in Informatics (OASIcs), Volume 128, pp. 2:1-2:14, Schloss Dagstuhl – Leibniz-Zentrum für Informatik (2025) https://doi.org/10.4230/OASIcs.NG-RES.2025.2

Abstract

Heterogeneous Multi-Processor Systems-on-Chip (MPSoCs) that combine multiple, heterogeneous processing units are becoming increasingly popular for a wide range of applications, including industrial applications, where complex real-time applications can benefit from the performance and flexibility they offer.
However, deploying real-time applications with low latency requirements across multiple processing units on such MPSoCs remains a challenging problem, particularly when communication between processors is required on a time-critical path. Existing solutions generally rely on the presence of at least one full-featured, general-purpose operating system on the device, and do not cater to the requirements of distributed, low-latency real-time applications.
In this paper, we investigate the performance, with a focus on latency, of different options for communication between CPUs, including inter-processor interrupts and shared memory communication via different memories, on the popular Xilinx Zynq UltraScale+ platform and propose a novel solution for communication between heterogeneous processing units that relies only on the availability of shared memory. Our solution is capable of achieving sub-microsecond latencies for signaling and the transfer of small amounts of data between processing units, making it suitable for deploying distributed, low-latency real-time applications.

Subject Classification

ACM Subject Classification
  • Computer systems organization → Real-time systems
  • Computer systems organization → Embedded software
  • Computer systems organization → Multicore architectures
Keywords
  • real-time systems
  • heterogeneous systems
  • latency
  • inter-core communication
